J+J J4C S300 Handbook

59
Index
DPS J4C 20/85
SPECIFICATIONS
MODEL S20-B20 S35-B35 S55-B55 S85-B85
Accuracy
3% F.S.
Linearity
2 % F.S.
Hysteresis
3 % F.S.
Steps at 4/20mA
Min. 150 steps 90º
Steps at 0/10V
Min. 98 steps 90º
Steps at 0/20mA
Min. 150 steps 90º
Steps at 1/10V
Min. 87 steps 90º
4/20mA or 0/20mA Input signal
impedance
100 Ohm
0/10V or 1/10V Input signal impedance
25 KOhm
Class B+C to E DIN EN 15714 Inching + Modulation
Weight
1,84 Kg 1,88 Kg 2,39 Kg 2,91 Kg
F.S. Full scale
HANDBOOK / OPTIONS DPS
