BSR J4C 20/85
SPECIFICATIONS
ACTUATOR MODEL S20-B20 S35-B35 S55-B55 S85-B85
No Working operation without recharge,
with 100% battery charge
min. 5 operations, works until battery discharged *
Recharge time / working operation 15 min 21 min 48 min 58 min
Battery consumption / working
operation
2,2 W 3,0 W 6,8 W 8,3 W
Full charge time 100%
28 h
Nominal capacity +/- 5%
2200 mAh
NO or NC Features (*)
Jumper
Current/one working operation with
battery
10,1 mA 14 mA 31,6 mA 38,6 mA
Battery charge
40 mA
Weight
1,99 Kg 2,03 Kg 2,50 Kg 3,02 Kg
HANDBOOK / OPTIONS BSR
* Our actuators are not designed to operate in single-acting mode. The BSR (Battery System Returns) is provided exclusively as an emergency system in case of power loss. It is recommended to
always keep them connected to the main electrical grid for reliable performance
