Index
BSR J4C 140/300
SPECIFICATIONS
ACTUATOR MODEL S140-B140 S300-B300
No Working operation without recharge,
with 100% battery charge
min. 4 operations, works until battery discharged *
Recharge time / working operation 30 min 50 min
Battery consumption / working
operation
23 W
Full charge time 100%
54 h
Nominal capacity +/- 5%
4400 mAh
NO or NC Features (*)
Jumper
Current/one working operation with
battery
15,1 mA 25,7 mA
Battery charge
40 mA
Weight
5,08 Kg
HANDBOOK / OPTIONS BSR
* Our actuators are not designed to operate in single-acting mode. The BSR (Battery System Returns) is provided exclusively as an emergency system in case of power loss. It is recommended to
always keep them connected to the main electrical grid for reliable performance
