Index
DPS J4C 140/300
SPECIFICATIONS
HANDBOOK / OPTIONS DPS
MODEL S140-B140 S300-B300
Accuracy 3% F.S.
Linearity 2 % F.S.
Hysteresis 3 % F.S.
Steps at 4/20mA Min. 150 steps 90º
Steps at 0/10V Min. 98 steps 90º
Steps at 0/20mA Min. 150 steps 90º
Steps at 1/10V Min. 87 steps 90º
4/20mA or 0/20mA Input signal impedance 100 Ohm
0/10V or 1/10V Input signal impedance 25 KOhm
Class B+C to E DIN EN 15714 Inching + Modulation
Weight 4,79 Kg
F.S. Full scale
