J+J J4C Series User Manual

93
Index
HANDBOOK / KIT INTERFACE
CONNECT THE INTERFACE CABLE TO THE J4C ELECTRIC ACTUATOR
J4C 20/85
J4C 140/300
Image 1
Image 2
1
2
Before connecting it to a J4C actuator, remove the cover of the actuator and connect one of the
Interface cable sides as per our image 1. Then connect the other cable side to a USB connector
on the PC (image (2).
Use the INTERFACE cable inside the KIT box.
J4C INTERFACE KIT
