Jet Research Center Drill Collar Severing Tool P/N 101293224 Rev. J
Page 18 of 20
Jet Research Center, 8432 South I-35W, Alvarado, Texas, 76009-9775, USA
Telephone 1-817-761-2000; Toll Free 1-800-451-5403; Fax 1-817-783-5812; Website www.jetresearch.com
7. Parts List and Assembly Diagrams
Item Description 1 3/8" Qty 1 3/4" Qty 2" Qty 2 5/8" Qty 2-1/8" HP Qty
100118390 1 101292915 1 101292956 1 101292957 1 101604779 1
1 Carrier Tube Assy 100157801 1 100157789 1 101292982 1 100157797 1 101540460 1
2A DCST Adapter 100157807 1 100158288 1 100157816 1 100158290 1 101538611 1
3 O-Ring 100158385 1 100158386 1 100158387 1 100158388 1 100158375 2
Cap Screw
1/4-20 UNC-2A X .188 100158394 4 100158394 4 100158394 4 100158394 4 100158394 4
5 End Clamp (Alum Washer) 100157806 1 101292904 1 101292911 1 101292912 1 101292911 1
6 MDF Sleeve N/A 101292901 1 101292902 1 101292903 1 101540498 1
Cap Screw
1/4-20 UNC-2A X .375 100158395 1 100158395 1 100158395 1 100158395 1 100158395 1
Set Screw
6-32 UNC-2A X .125 100158393 1 N/A N/A N/A N/A
8-32 UNC-2A X .188 N/A 100158396 1 100158396 1 100158396 1 100158396 1
9 Spacer Spring 100157803 1 101205992 1 101205994 1 101205995 1 101205994 1
10A Extension Mandrel Assy 100158260 1 100008258 2 100008258 2 100008258 2 101539987 1
19 Firing Head Assembly Not Included Not Included Not Included Not Included 100157532 1
13A Detonator - RED Top Fire 101272595 101272595 101272595 101272595 101272595
13B HT Resitorized Detonator D1208 100000432 100000432 100000432 100000432 100000432
14 MDF Assembly 100118417 1 100118417 1 100118417 1 100118417 1 100118417 1
15 Explosive Kit, consisting of: 101214053 1 101293167 1 101293168 1 101293152 1 101293168 1
15.1 Pellets (HMX) 100118418 (28) 100015145 (44) 100118425 (64) 101293160 (110) 100118425 (64)
15.2 Cartridges (HMX) 100118419 (2) 100015146 (2) 100118426 (2) 101293161 (2) 100118426 (2)
15A Explosive Kit, consisting of: 101237459 1 101293207 1 101293234 1 101293235 1 101293234 1
15.1A Pellets (HNS) 120135256 (28) 100118421 (44) 101015435 (64) 101295855 (110) 101015435 (64)
15.2A Cartridges (HNS) 120135257 (2) 100118422 (2) 101015436 (2) 101295856 (2) 101015436 (2)
11A Adapter for RED (w/ O-Ring) 120042268 1 101293676 1 101293676 1 101293676 1
12 O-Ring for Adapter 100158373 1 100158373 1 100158373 1 100158373 1
16 Shunt Plug 100118431 1 100010861 1 100010861 1 100010861 1 100010861 1
17 Protective Holder 100010862 1 100010862 1 100010862 1 100010862 1 100010862 1
18 Loading Tool 100118432 1 100118432 1 100118432 1 100118432 1 100118432 1
19 Firing Head Assembly 100118430 1 100000434 1 100000434 1 100000434 1 in kit (19) 1
20 2-1/8" HP DCST Adapter for RED N/A N/A N/A N/A 102273068 1
2B DCST Adapter in kit (2A) 1 101293169 1 101293187 1 101293220 1
10B Extension Mandrel 1-1/2" N/A 101293227 1 101293227 1 101293227 1
Extension Mandrel 1-3/8" 101293225 1 N/A N/A N/A
11B Adapter for RED 120042268 1 101293230 1 101293230 1 101293230 1
Hardware Kit, consiting of:
Parts in kit,rated for 26,00K
PSI
Use item 20 to replace
DCST Adapter
Required Equipment (must be ordered seperately)
HP Accessories (For applications in excess of 15,000 PSI up to 20,000 PSI)
Table 4. Drill Collar Severing Tools Parts List
