JMA-9100 series
– system  exibility
Theme based navigation
With JRC’s new radar series you don’t have to settle for one
constant setting throughout, integrating four navigation themes,
facilitating the most optimised radar image, particularly valuable
to the dynamically changing conditions. For speci c areas,
decide on coastal or deep-sea mode and for weather, JRC has a
storm and rain mode integrated. JRC-designed themes are easy
to customise, so you can adjust and set your radar image exactly
as you want.
More built-in ergo-flexibility
The trackball is designed to work in perfect harmony with the operating system. One of
the new features in this radar series is that you can e ortlessly assign commonly used
functions to the left mouse button, giving you the capability to access a preferred function
without having to take your hand o the trackball. You can assign and reassign this multi-
button with a range of operational features, which among others are AIS info, TT ACQ,
show TT data, property, make mark.
What’s standard in the box?
JRC sets the highest standards for performance and  exibility. With our new JMA-9100 series, you have six key choices
to select from, allowing you to ‘con gure’ your favoured radar system – from unit type to cabling – making it more
than ideal for your preferred installation approach.
X-band or
S-band?
cable length
selection?
2-unit or 3-unit
type?
transmitting
power?
desktop or
stand alone?
conventional or
high-speed?
Your choices
conventional 7
high-speed 2
both versions
available in all
9 models
10kW 2
25kW 5
30kW 2
2-unit 6
3-unit 3
standard and
selectable -
max up to 65m
X-band 7
S-band 2
Models available
JMA-9110-6XA JMA-9110-6XAH JMA-9122-6XA JMA-9122-9XA JMA-9122-6XAH JMA-9123-7XA JMA-9123-9XA JMA-9132-SA JMA-9133-SA
2-unit 2-unit 2-unit 2-unit 2-unit 3-unit 3-unit 2-unit 3-unit
10kW 10kW 25kW 25kW 25kW 25kW 25kW 30kW 30kW
X-band X-band X-band X-band X-band X-band X-band S-band S-band
CHSC CHSC C C C
cable type 1 cable type 1 cable type 2 cable type 2 cable type 1 cable type 3 cable type 3 cable type 2 cable type 3
Scanner to display own choice 5, 10, 20, 30, 40 and/or 65 m max 65 m
Cable type 1
Scanner to display standard 40 m max 65 m
Cable type 2
Scanner to transceiver own choice 20 or 30 m
Scanner to transceiver (waveguide) own choice 20 or 30 m
Transceiver to display standard 35 m
(!) The total maximum length for cable type 3 (scanner to display) must not exceed 65 m.
Cable type 3
TT = Target Tracking = ARPA
