xii
JMA-7110-6XA/6XAH
Tab l e1- 3 ： JMA-7100 SERIES RADAR LIST OF COMPOSITION (Self-Standing TYPE)
Tab l e1- 4 ： JMA-7100 SERIES RADAR LIST OF COMPOSITION (Desktop TYPE)
Scanner Unit: NKE-2103
Table1-17： JMA-7110-6XA/JMA-7110-6XAH SCANNER UNIT
2.1.1 CFQ-6912-**
2.2.1 NKE-2103 type scanner
2.4 PRECAUTIONS
Display Unit (self standing): NCD-4790
Table1-18： NCD-4790/NCD-4790T DISPLAY UNIT
3.1 INSTALLATION OF DISPLAY UNIT
3.2 INSTALLATION OF AC-DC CONVERTER NBA-5135
3.3.2 Connections with NKE-2103,NKE-2254
OPTION Interswitch Unit: NQE-3141-2/4A/8A
5.1 INSTALLATION OF INTERSWITCH UNIT
Power Control Unit: NQE-3167
5.2.1 Connection with NKE-2103 type and NKE-2254-6HS type
scanners
5.2.5 Connection to display unit
VDR I/F Kit: CQD-1891
5.3 INSTALLATION OF VDR
