applied on the back of the wall prole
before installation.
FIG. 7
7. Put the glass (2) in the wall prole (1).
There is an adjustment margin of 10 mm.
8. Fasten the glass in the wall prole with
screws (8).
FIG. 8
9. Position the bar against the product and
keep it horizontal.
10. Mark the position of the short telescopic
parts (3) and drill mounting holes.
FIG. 9
11. Put the protective lm (6) on the glass
and t the retaining clip (5).
12. Put the long part of the bar (4) between
the short part (3) and the clip (5). Screw
tight the screws.
FIG. 10
13. Apply glass adhesive between the product
and the underlayer. Wait 24 hours before
using the product.
FIG. 11
