Jula EKVIP 024302 - Safety Instructions; Technical Data; Installation

EN
18
SYMBOLS
Read the instructions.
Approved in accordance with
the relevant directives.
TECHNICAL DATA
Width 90 cm
Depth 70-110 cm
Height 200 cm
Weight 28 kg
DESCRIPTION
Shower screen made of 6 mm toughened
safety glass with aluminium proles. The bar is
adjustable in length (70–110 cm) and acts as
an attachment of the glass screen.
INSTALLATION
FIG. 2
FIG. 3
FIG. 4
FIG. 5
1. Fit the sealing strip (7) on the bottom
edge of the glass (2).
2. Measure out the installation area and
mark with vertical lines on the wall.
FIG. 6
3. Mark out the position of the holes along
the vertical line on the wall. Maintain
vertical position.
4. Drill holes in the wall with 6 mm drill.
5. Put plugs (9) in the holes.
6. Screw the wall prole (1) in place with
4 x 35 mm screws (9). Glass glue can be
SAFETY INSTRUCTIONS
• For safety reasons the product is made of
toughened glass. Such glass is very tough,
but if subjected to knocks or blows it can
later crack unexpectedly.
• Make sure not to subject the product to
knocks or distortion during installation or
use.
• Install the product so that there is no risk
of subjecting it to knocks.
• Do not allow children to play with the
product.
• Do not put stickers or adhesive lm on the
glass. If the glass cracks it can crack into
large pieces, which can result in a risk of
personal injury.
• Read these instructions carefully before
installation and use. Failure to follow all
instructions and safety instructions can
result in a risk of personal injury and/or
material damage. Save these instructions
for future reference.
• Do not hang or climb on the walls, they
are not made to withstand stress.
WARNING!
Glass is very fragile. Wear safety gloves when
handling it.
TYPE PLATE
1. The product complies with the relevant EU
directives.
2. Year of approval.
3. Intended use personal hygiene.
4. Designation for European Standard.
5. Complies with requirements for cleaning.
6. Complies with requirements for shock-
resistance/shattering.
7. Complies with requirements for durability.
FIG. 1
