ASSEMBLY INSTRUCTIONS
Step 9
Note: always fold up the gas cylinder mounting base before folding the trolley.
To fold up the gas cylinder mounting base (E), simply lift it up as shown below.
E
1
2
To fold down the gas cylinder mounting base (E), push the right side of the frame
over to the left and fold down.
