Jumper JP4IN1 - PPM Mode Operation

CG023
CG023
YD829
H8_3D
BAYANG
Nil
Jumper X68T
FRSKYX
CH_16
Frsky protocol, D16 mode
CH_8
Frsky protocol, D8 mode
ESKY
Nil
Esky protocol
MT99XX
MT99
H7
YZ
LS
MJXQ
WLH08
X600
X800
MJX series protocol
H26D
E010
E010 and JJR H36 protocol
SHENQI
Nil
FY326
Nil
S-FHSS
Nil
Futaba S-FHSS
protocol(updating)
J6PRO
Nil
Nine Eagle J6PRO protocol
FQ777
Nil
ASSAN
Nil
FRSKYV
Nil
Frsky V series protocol
HONTAI
FORMAT_HONTAI
FORMAT_JJRCX1
FORMAT_X5C1
More details, please refer to::
https://github.com/pascallanger/DIY-Multiprotocol-TX-Module
2. Normal operation in PPM mode (JP4IN1 only receives one-way analog coded
signal from radio.)
PPM mode is used for PPM signal output, and the mounting slot of radio is compatible with
JP4IN1 (F.E. JR). There are total 31 different protocols that correspond to the 16 positions of the
encoder knob in the PPM mode (“0” position is reserved for serial mode). Check the list on the
last page of the manual for corresponding relationship between them.
