Jumpking RECTANGULAR 12 - FRAME PART LIST; Frame Component Details

60 JK-R12-A1
4
6
1 8
7
5
2
3
9
10
FRAME PART LIST
Pos Description Quantity
1 L-leg 8
2
3
4
L-Top tube “A” 2
Top tube “C” 2
Top tube “E” 25
Top tube “B” 4
6 L-top tube “D” 2
7 T-connector with 1 welded
tube
8
8
Pos Description Quantity
9
Centre leg 4
10
Bottom pole rectangular 32
mm
8
Top pole rectangular 32 mm 8
63
