5. Once completed, the skeleton of the
Trampoline should look like the
Figure 5.
Mat Assembly
To facilitate the assembly of the springs to the mat, please use the Spring Hook
provided to pull the springs during assembly.
1. Spread out the Mat (1) and have both
the Springs (7) and Spring Hook ready
for assembly as shown in Figure 1.
2. Divide the Mat into halves and then
connect the first set of Springs (7) as
shown in Figure 2.
Page: 7 (Version 2)
