6
Anschluss
1 2 3 4 5
–
+24 V
+24 V
1 2 3
+24 V
–
4
Montage ausschließlich von Elektrofachkraft durchführen lassen!
Adapter (5-polig)
Stecker (verpolungssicher)
HINWEIS
8-737-704-462-0
EU1D
8-737-704-461-0
EU2D
