Maintenance of the pump JUWEL Eccoflow in the filter system Compact,
Standard H, Jumbo
The pump JUWEL Eccoflow should be checked with regard to funconality and cleaned at regular intervals (at least once a month).
Please proceed as follows:
1. Disconnect all electrical devices of the aquarium from the power grid.
2. Remove the outlet nozzles.
3. Remove the pump from the filter.
4. Disconnect the pump adapter (C) and the connecon ring (B) from the motor by turning them counter-clockwise and remove the
impeller.
5. Thoroughly clean all components. It is parcularly necessary to remove the impeller from the chamber and remove deposits and
dirt from the chamber itself as well as the impeller. The funcon of the pump will be impaired otherwise. Also check the impeller
for damage and possible signs of wear of the magnet.
Aer that, please reinstall the pump in reverse order in the filter.
