Montageanleitung Art.-Nr. 20146
O P Q R S T U
2 x 2 x 4 x 2 x 8 x 4 x 2 x
25936 26545 22807 25937 26398 26399 26824
A B C D E F G
~ 970 x 480 mm
Türmaß (B x H)
~ 285 x 340 mm
~ 970 x 400 mm
~ 705 x
485/410 mm
~ 705 x
485/410 mm
~ 739 x 485 mm
Winkel kurz
corner short
angle court
hoek kort
Aluminium
~ 382 mm
Winkel lang
corner long
angle long
hoek lang
Aluminium
~ 459 mm
1 x 1 x 1 x 1 x 2 x 2 x 2 x
52597 52601 52591 52592 52521 52398 52396
H I J K L M N
H
4
H
1
H
3
SW
Aluminium
~ 664 mm
INOUT
SW
Aluminium
~ 705 mm
~ 980 x 765 mm
1 x 2 x 2 x 8 x 1 x 1 x 1 x
25932 52293 52782 25939 52204 26782 25941
Teileliste | Part list | Liste des pièces fournies | Lista delle parti:
Werkzeug notwendig! Required tools!
Outils nécessaires ! Gereedschap nodig!
