Page 10

Z-Series Quick Start Manual

Command Key1 Key2 Keys 3 and 4 Key5

Exit Programming

Mode

* #

1.6.1 Relay Funcons

The table below is for use for the relay programming opons menoned in the table on the previous page.

Keys 3

and 4

Funcon Descripon

00 Fence Triggers when Zone 1 is Armed and Return Voltage is below the Threshold Voltage

01 Fence or O Triggers when Zone 1 is Disarmed or Return Voltage is below the Threshold Voltage

02 Armed Zone 1 is Armed

06 Fence Bi-Polar Triggers when energizer is Armed and the fence Return Voltage on either Bi-Polar re-

turn line has fallen below the Threshold Voltage

07 General Triggers on AC Fail, Tamper, Low Baery/Bad Baery, Gate Alarm or Internal error.

Latched (internal errors only)

08 Siren Triggers on Fence Alarm, Gate or Tamper. Will me out aer the Siren Time Out me.

Latched

09 Strobe Triggers on Fence alarm, Gate or Tamper. Only turns o on Energizer Disarm. Latched

10 AC Fail Triggers on AC Fail

11 Low/Bad Battery Triggers on Low or Bad Battery

12 Tamper Triggers when the case has been opened and J3 has been tted (Z14R only)
