AV-21F4EE
No. 56006C2
AV-21FT AV-21F4EE(SK)
!!
!!
! REF. NO. PART NAME DESCRIPTION
PART No. PART No.
■ EXPLODED VIEW PARTS LIST (Page 28)
! V01 A51JSY33X/C/ PICTURE TUBE
A51JSY63X15/C/ PICTURE TUBE ITC type (with DEF YOKE)
DY01 QQD0041-001 DEF YOKE
1 LC10394-026A-H LC10394-027A-HK FRONT CABINET
! 14 LC10448-002B-H LC10448-002B-HK REAR COVER
! 15 LC20377-010B-H LC20377-015A-H RATING LABEL
18 A75034-B PC MAGNET
19 CE40764-00A WEDGE ASSY
■ PRINTED WIRING BOARD PARTS LIST (Page 30-)
— SCG-1233A-H2 SCG-1255A-H2 MAIN PWB ASSY
C1582 QFZ0199-274 MPP CAP. 0.27µF 250V J
QFZ0199-204 MPP CAP. 0.2µF 250V J
■ PACKING PARTS LIST (Page 34)
1 GG10056-005A-H GG10056-006A-H PACKING CASE
! 7 LCT0748-001A-H LCT0751-001A-H INST BOOK
! 8 LCT0749-001A-H DIGEST MANUAL
! — LCT0862-001A-H INST SHEET
PARTS DIFFERENCE TABLE
The different parts between AV-21FT and AV-21F4EE(SK) are described below:
