JVC AV-21F4EE - Deflection Circuit Adjustment; VSM Preset Adjustment

AV-21F4EE
No. 56006C6
■ DEFLECTION CIRCUIT ADJUSTMENT (Page 20)
: Do not adjust.
■ VSM PRESET ADJUSTMENT (Page 22)
VSM preset
VSM mode BRIGHT STANDARD SOFT
Setting item
TINT
+15
bb
bb
b
bb
bb
b
SETTING VALUE
COLOUR
+15
bb
bb
b
bb
bb
b
SETTING VALUE
BRIGHT
+15
bb
bb
b
bb
bb
b
SETTING VALUE
CONT.
+30 +15 +11
SETTING VALUE
SHARP
+15 +15 +12
SETTING VALUE
[Setting Values for SUB MENU 4. VSM PRESET]
Initial setting value
Setting item Adjustment name Variable range
50Hz 60Hz
1. VER. POSITION Vertical center −4 ~ +3 −1 −3
2. HOR. POSITION Horizontal center −16 ~ +15 +3 +3
3. VER. HEIGHT Vertical height −64 ~ +63 −35 +1
4. VER. LINEARITY Vertical linearity −32 ~ +31 +15 −1
5. VER. SCURVE Vertical scurve −32 ~ +31 −32 0
6. HOR. VCO ADJUST Horizontal VCO −64 ~ +63 0 0
: Do not adjust.
[SUB MENU 4. DEF]
