JVC AV-28BD5EKI - Specific Service Instructions; Disassembly and Rear Cover Removal

No.51709
A
V-28BD5EKI AV-28BD5EP AV-28BD5EE
A
V-28BD5EKIS AV-28BD5EPS AV-28BD5EES
1-8
SPECIFIC SERVICE INSTRUCTIONS
DISASSEMBLY PROCEDURE
Note : Before starting work, disconnect the power plug from the wall outlet.
HOW TO REMOVE THE REAR COVER
1. Remove the 11 screws marked
A
.
2. Remove the rear cover backward.
A
CRT
CRT SOCKET PWB
FBT
TUNER
PWB
POWER SW.
SPEAKER
FRONT CABINET
