No.51709
V-28BD5EKI AV-28BD5EP AV-28BD5EE
V-28BD5EKIS AV-28BD5EPS AV-28BD5EES
1-4
21-pin EURO-SCART 2 [AV2]
Pin
No.
Signal Designation Matching Value
1NC
2
Audio Intput
!
Right
0.5V(rms), Impedance :<10k
Ω
3NC
4Audio Earth
5Earth
6 Audio Input Left
0.5V(rms), Impedance :>10k
Ω
7NC
8NC
9NC
10 NC
11 NC
12 NC
13 Earth
14 Earth
15 Chroma Input
±
3dB for a luminance signal of 1V(p-p)
16 NC
17 Earth
18 Video In Earth
19 NC
20 Video Input, Y In.
1V(p-p)
±
3dB, Impedance :75
Ω
21 Common Earth
[
Pin assignment
]
