No. 51695B
AV-28WFR1EKS
AV-28WFR1EK
3
POWER & DEF. PW BOARD ASS’Y(Page 41~42)
PW BOARD No. SJK-2504A-U2
SJK-2508A-U2
!
Symbol No.
PARTS No. PARTS No.
PARTS NAME DESCRIPTION
R2403 QRE141J-123
QRA14CF-3091Y
CR 3.09kΩ 1/4W F
R2414 QRE121J-3R9Y
QRE121J-100Y
CR 10Ω 1/2W J
R2467 QRG039J-120
QRL039J-330
OM R
33Ω 3W J
R2551 QRT039J-3R3
QRT039J-1R5
MF R 1.5Ω 3W J
R2552 QRT039J-3R3
QRT039J-1R5
MF R 1.5Ω 3W J
!
R2554 QRZ9021-1R5
QRZ9022-R47
FR
0.47Ω 1W J
!
R2556 QRZ9011-4R7 FUSI. RESISTER Delete
!
R2557 QRZ9021-100 FUSI. RESISTER Delete
C2461 QETN2AM-475Z
QEZ0195-475Z
E CAP.
4.7μF 50V M
!
C2521 QFZ0200-352
QFZ0200-282
MPP CAP. 2800pF 1.5kVH ±3％
!
C2523 QFP32GJ-223
QFP32GJ-183
PP CAP. 0.018μF 400V J
C2524 QFM72DK-104
QFM72DK-563
M CAP.
0.056ΜF 200V K
C2525 QFZ0199-354 MPP CAP. Delete
C2526 QFZ0199-254
QFZ0197-304
MPP CAP. 0.3μF 250V J
C2528 QFZ0199-683 MPP CAP. Delete
C2529 QFZ0199-104
QFZ0197-473
MPP CAP.
0.047μF 250V J
C2532 QFZ0199-334 MPP CAP. Delete
C2542 QFZ0199-204
QFZ0197-434
MPP CAP. 0.43μF 250V J
C2543 QFZ0199-154
QFZ0197-184
MPP CAP.
0.18μF 250V J
C2561 QFLC1HJ-683Z
QFV71HJ-184Z
M CAP 0.18μF 50V J
T2521 CE42549-001J1 BRIGE COIL Delete
!
T2551 QQH0065-002-I2
QQH0089-001
FBT
T2561 QQR0898-001
QQH0898-001
DEF.TRANSF.
L2461 QQLZ028-822
QQLZ027-821
CHOKE COIL
L2521 QQLZ028-101
QQLZ028-501
CHOKE COIL
D2403 1SS133-T2 SI.DIODE Delete
D2555 MTZJ12C-T2 ZENER DIODE Delete
D2556 MTZJ12C-T2 ZENER DIODE Delete
K2501 CE41433-001Z BEADE CORE Delete
K2502 CE41433-001Z BEADE CORE Delete
!
PC2901 TLP721F(D4-GR)
TLP421F/D4-GR/
I.C. (PH.COUPLER)
