JVC AV-28WFR1EKS - Page 6

No.51729
A
V-29RX
2
SPECIFICATIONS
Item CONTENTS
Dimensions ( W
×
××
×
H
×
××
×
D )
732mm
×
588mm
×
508mm
Mass
52.0kg
TV RF System
B, G, I, D, K, K1, M
Colour System
PAL, SECAM, NTSC3.58, NTSC4.43
Stereo System
Play back stereo only
Receiving Frequency
VHF(L)
46.25MHz
～
168.25MHz
VHF (H)
175.25MHz
～
463.25MHz
UHF
471.25MHz
～
863.25MHz
CATV
Mid(X-Z, S1-S10), Super(S11-S20), Hyper(S21-S41) bands receivable
Intermediate Frequency
VIF Carrier
38.0MHz
SIF Carrier
33.5MHz(4.5MHz), 32.5MHz(5.5MHz), 32.0MHz(6.0MHz), 31.5MHz(6.5MHz)
Colour Sub Carrier Frequency
PAL
4.43MHz
SECAM
4.40625MHz, 4.25MHz
NTSC
3.58MHz / 4.43MHz
Power Input
AC 110V
～
240V , 50/60Hz
Power Consumption
193W(Max) / 137W(Avg)
Picture Tube
Visible size : 68cm measured diagonally
High Voltage
32.0kV
±
1.5kV (at zero beam current)
Speaker & Audio Output
Open dome speaker 10cm round
×
2, 10W+10W
Video Audio Input terminals
S-Video
Y : 1V
(p-p)
positive (Negative sync provided, when terminated with 75
Ω
)
C : 0.286V
(p-p)
(Burst signal, when terminated with 75
Ω
)
Video
1V
(p-p)
75
Ω
(RCA pin jack)
Video1
Audio(L/R)
500mV(rms) (-4dBs), High impedance (RCA pin jack)
Video
1V
(p-p)
75
Ω
(RCA pin jack)
Video2
Audio(L/R)
500mV(rms) (-4dBs), High Impedance (RCA pin jack)
Video/Y
V : Composite video 1V
(p-p)
75
Ω
(RCA pin jack)
Y : Component video 1V
(p-p)
75
Ω
(RCA pin jack)
Cb
Component video B-Y 0.7V
(p-p)
75
Ω
(RCA pin jack)
Cr
Component video R-Y 0.7V
(p-p)
75
Ω
(RCA pin jack)
Video3
Audio(L/R)
500mV(rms) (-4dBs), High Impedance (RCA pin jack)
S-Video
Y : 1V
(p-p)
positive (Negative sync provided, when terminated with 75
Ω
)
C : 0.286V
(p-p)
(Burst signal, when terminated with 75
Ω
)
Video
1V
(p-p)
75
Ω
(RCA pin jack)
Video4
(
Front terminal
)
Audio(L/R)
500mV(rms) (-4dBs), High impedance (RCA pin jack)
Video Audio Output terminal
Video
1V
(p-p)
75
Ω
(RCA pin jack)
Audio(L/R)
500mV(rms) (-4dBs), High Impedance (RCA pin jack)
Aerial Input Term
75
Ω
unbalanced, Coaxial
Headphone jack
Stereo mini jack (
φ
3.5mm )
AV Compu Link terminal
AV Compu Link
Ⅱ
, mini jack (
φ
3.5mm )
Remote Control Unit
RM-C113 (AA/R06 dry battery
×
2)
Design & specifications are subject to change without notice.
