– 30 –
English
Specifications
Amplifier
Output Power (IEC 268-3/DIN)
Front:
75 W per channel, min. RMS, both channels driven into 6 Ω at 1
kHz with no more than 0.9% total harmonic distortion.
Center:
25 W, min. RMS, driven into 8 Ω at 1 kHz with no more than 0.9%
total harmonic distortion.
Rear:
12.5 W per channel, min. RMS, both channels driven into 16 Ω at 1
kHz with no more than 0.9% total harmonic distortion.
Audio input sensitivity/Impedance (at 1 kHz)
AUX: 400 mV/50 kΩ
Audio output level:
AUX: 270 mV
Digital output: CD OPTICAL DIGITAL OUTPUT
Signal wave length: 660 nm
Output level: –21 dBm to –15 dBm
Speakers/Impedance:
Front: 6 Ω – 16 Ω
Center: 8 Ω – 16 Ω
Rear: 16 Ω – 32 Ω
Tuner
FM tuning range: 87.50 MHz – 108.00 MHz
AM tuning range: MW: 522 kHz – 1,629 kHz
LW: 144 kHz – 288 kHz
CD player
CD Capacity: 3 CDs
Dynamic range: 85 dB
Signal-to-noise ratio: 90 dB
Wow and flutter: Immeasurable
Cassette deck
Frequency response
Normal (type I): 50 Hz – 14,000 Hz
CrO
2 (type II): 50 Hz – 14,000 Hz
Metal (type IV): 50 Hz – 14,000 Hz (only for playback)
Wow and flutter: 0.15% (WRMS)
General
Power requirement: AC 230 V , 50 Hz
Power consumption: 140 W (at operation)
14 W (at standby mode)
Dimensions (approx.): 265 mm x 315 mm x 341 mm (W/H/D)
(10
7
/16 in. x 12
7
/16 in. x 13
7
/16 in.)
Mass (approx.): 9.5 kg (20.9 lbs)
Supplied accessories
See page 6.
Design and specifications are subject to change without notice.
