1-2 (No.YD027)
SPECIFICATION
E.& O.E. Design and specifications subject to change without notice.
• Manufactured under licence from Dolby Laboratories. “Dolby” and double-D symbol are trademarks of Dolby Laboratories.
• “DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.
• SHOWVIEW is a registered trademark of Gemstar Development Corporation. The SHOWVIEW system is manufactured under licence from Gemstar
Development Corporation.
• This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property
rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited viewing users only unless otherwise authorized by Macrovision Corporation. Reverse engi-
neering or disassembly is prohibited.
• VIDEO Plus+ and PlusCode are registered trademarks of Gemstar Development Corporation. The VIDEO Plus+ system is manufactured under li-
cense from Gemstar Development Corporation.
DR-MH20SE,DR-MH30SE,DR-MH30SER DR-MH20SEK,DR-MH30SEK DR-MH20SEF,DR-MH30SEF
GENERAL
Power requirement AC 220 V - 240 V~, 50 Hz/60 Hz
Power consumption Power on : 37 W
Power off : 19.3 W
Temperature Operating : 5°C to 40°C
Storage : -20°C to 60°C
Operating position Horizontal only
Dimensions (W × H × D) 435 mm × 70 mm × 345.5 mm
Weight 6.1 kg
Input/Output
S-video input Y:0.8-1.2 Vp-p, 75 ohms
C : 0.2 -0.4 Vp-p, 75 ohms
S-video output Y : 1.0 Vp-p, 75 ohms
C : 0.3 Vp-p, 75 ohms
Video input 0.5- 2.0 Vp-p, 75 ohms (pin jack)
Audio input -8 dB, 50 kilohms (pin jack)
Corresponding to mono (left)
Audio output -8 dB, 1 kilohms (pin jack)
i.Link 4-pin for DV input
Component video output Y : 1.0 Vp-p, 75 ohms
CB/CR, PB/PR: 0.7 Vp-p, 75 ohms
Corresponding to copy protection
Digital audio output Optical: -18 dBm, 660 nm
Coaxial: 0.7 Vp-p, 75 ohms
Corresponding to Dolby Digital and DTS Digital Surround Bit stream
Selectable in digital audio output setting menu
RCA connectors IN x 1, OUT x 1
VIDEO/AUDIO (DVD Deck)
Recording time
Maximum 8 hours (with 4.7 GB disc)
(XP) : Approx. 1 hour, (SP) : Approx. 2 hours, (LP) : Approx. 4 hours, (EP) : Approx. 6 hours, (FR) : Approx. 1 hour - 8 hours
Audio recording system Dolby Digital (2 ch)
Linear PCM (XP mode only)
Video recording compression system MPEG2 (CBR/VBR)
VIDEO/AUDIO (HDD Deck)
Video recording compression system MPEG2 (VBR)
Audio recording system Dolby Digital (2 ch)
Linear PCM (XP mode only)
Recording time
Maximum 204 hours
(XP): Approx. 34 hours,(SP): Approx. 68 hours,(LP): Approx. 136 hours,(EP): Approx. 204 hours,(FR480): Approx. 272 hours
TUNER/TIMER
Signal system PAL-type colour signal and CCIR monochrome signal, 625 lines 50 fields
-
TV channel storage capacity 99 positions (+AUX position)
Tuning system Frequency synthesized tuner
Channel coverage
(SECAM-L)
-
VHF(LOW):49 MHz-65 MHz(2-4)
VHF(HIGH):104 MHz-300 MHz(5-10CATV)
Hyper:300 MHz-470 MHz(CATV)
UHF:470 MHz-862 MHz(21-69)
Channel coverage(PAL) VHF(LOW): 47 MHz-89 MHz
VHF(HIGH):104 MHz -300 MHz
Hyper:302 MHz-470 MHz
UHF 470 MHz-862 MHz
VHF(LOW):44.5 MHz-143 MHz
VHF(HIGH):143 MHz-470 MHz
UHF: 470 MHz-862 MHz
VHF(LOW):47 MHz-89 MHz
(E2-E4,X,Y,Z)
VHF(HIGH):104 MHz-300 MHz
(E5-E12,S1-S20,M1-M10,U1-U10)
Hyper:302 MHz-470 MHz(S21-S41)
UHF:470 MHz-862 MHz(E21-E69)
Memory backup time Approx. 60 seconds
ACCESSORIES
Provided accessories
RF cable,21-pin SCART cable,Satellite Control-
ler,Infrared remote control unit,”R6” battery x 2
RF cable,21-pin SCART cable,Satellite Control-
ler,Infrared remote control unit,”AA” battery x 2
RF cable,21-pin SCART cable,Satellite Control-
ler,Infrared remote control unit,”R6” battery x 2
