2.5.3 Suggested servicing schedule for main components
The following table indicates the suggested period for such ser-
vice measures as cleaning, lubrication and replacement. In prac-
tice, the indicated periods will vary widely according to
environmental and usage conditions. However, the indicated
components should be inspected when a set is brought for ser-
vice and the maintenance work performed if necessary. Also
note that rubber parts may deform in time, even if the set is not
used.
C : Cleaning
X : Inspection or Replacement if necessary
System Parts name
Operation hours
1000H 2000H
Tape
transport
Drum assembly C,X X
A/C head C,X C,X
Pinch roller arm assembly C C
Full erase head C C
Tension arm assembly C C
Capstan motor (Shaft) C C
Guide arm assembly C C
Drive
Capstan motor X
Capstan brake assembly X
Main brake assembly X
Belt (Capstan) X X
Loading motor X
Clutch unit X
Worm gear X
Control plate X
Other Rotary encoder X
To Next Page
