3-10(No.YD084)
Main board
Block No. [0][3]
Symbol No.
Part No. Part Name Description Local
PW1 LPA10293-13C MAIN BOARD ASSY E
PW1 LPA10293-15C MAIN BOARD ASSY EF
PW1 LPA10293-14C MAIN BOARD ASSY EK
IC1 JCP8060-MSA IC
IC201 LC74788N-9751-E IC
IC501 BH7623KS2 IC
IC2201 AN3651FBP IC
IC2601 RC4558D-X IC
IC2601 or BA15218F-XE IC
IC2602 CD4052BM-X IC
IC2603 RC4558D-X IC
IC2603 or BA15218F-XE IC
IC2604 CD4052BM-X IC
IC2605 RC4558D-X IC
IC2606 LA7151-E IC
IC2607 LA7151-E IC
IC3001
HD6432194SAE18F
IC(MCU) MASK EF
IC3001
HD6432194SAE17F
IC(MCU) MASK E,EK
IC3002
S-80827CNNB-G-W
IC
IC3002 or IC-PST3427U-X IC
IC3003 LPN1009-001D-31 IC(EEPROM)
*(REFER TO BELOW)
E
IC3003 LPN1009-003C-33 IC(EEPROM)
*(REFER TO BELOW)
EF
IC3003 LPN1009-002D-32 IC(EEPROM)
*(REFER TO BELOW)
EK
IC3601 BU2090FS-X IC
IC4201 LC74793-E IC
IC4202 MM1504XN-X IC
IC4301 LA7357M-E-W IC EF
IC4304 74HC4538D-X IC EF
IC7101
CD74HC4053PW-X
IC
IC7501 SN74LV08APW-X IC
Q7
2SC2412K/QRS/-X
TRANSISTOR
Q7 or 2SD601A/QRS/-X TRANSISTOR
Q7 or
2SC3928A/QRS/-X
TRANSISTOR
Q8
2SC2412K/QRS/-X
TRANSISTOR
Q8 or 2SD601A/QRS/-X TRANSISTOR
Q8 or
2SC3928A/QRS/-X
TRANSISTOR
Q9
2SC2412K/QRS/-X
TRANSISTOR
Q9 or 2SD601A/QRS/-X TRANSISTOR
Q9 or
2SC3928A/QRS/-X
TRANSISTOR
Q10
2SC2412K/QRS/-X
TRANSISTOR
Q10 or 2SD601A/QRS/-X TRANSISTOR
Q10 or
2SC3928A/QRS/-X
TRANSISTOR
Q16 2SA1037AK/QR/-X TRANSISTOR
Q16 or 2SB709A/QR/-X TRANSISTOR
Q16 or 2SA1530A/QR/-X TRANSISTOR
Q202
2SC2412K/QRS/-X
TRANSISTOR
Q202 or 2SD601A/QRS/-X TRANSISTOR
Q202 or
2SC3928A/QRS/-X
TRANSISTOR
Q203 2SA1037AK/QR/-X TRANSISTOR
Q203 or 2SB709A/QR/-X TRANSISTOR
Q203 or 2SA1530A/QR/-X TRANSISTOR
Q501 2SA1037AK/QR/-X TRANSISTOR
Q502
2SC2412K/QRS/-X
TRANSISTOR
Q503 2SA1037AK/QR/-X TRANSISTOR
Q504 DTC144WKA-X DIGI TRANSISTOR
Q504 or UN221E-X TRANSTSTOR
Q504 or RT1N44HC-X DIGI TRANSISTOR
Q2001
2SC2412K/QRS/-X
TRANSISTOR
Q2001 or 2SD601A/QRS/-X TRANSISTOR
Q2001 or
2SC3928A/QRS/-X
TRANSISTOR
Q2002
2SC2412K/QRS/-X
TRANSISTOR
Q2002 or 2SD601A/QRS/-X TRANSISTOR
Q2002 or
2SC3928A/QRS/-X
TRANSISTOR
Q2003 DTA144WKA-X TRANSISTOR
Q2003 or UN211E-X DIGI TRANSISTOR
Q2003 or RT1P44HC-X DIGI TRANSISTOR
Q2051
2SC2412K/QRS/-X
TRANSISTOR
Q2051 or 2SD601A/QRS/-X TRANSISTOR
Q2051 or
2SC3928A/QRS/-X
TRANSISTOR
Q2052 2SA1037AK/QR/-X TRANSISTOR
Q2052 or 2SB709A/QR/-X TRANSISTOR
Q2052 or 2SA1530A/QR/-X TRANSISTOR
Q2053 DTC144WKA-X DIGI TRANSISTOR
Q2053 or UN221E-X TRANSTSTOR
Q2053 or RT1N44HC-X DIGI TRANSISTOR
Q2054 2SA1037AK/QR/-X TRANSISTOR
Q2054 or 2SB709A/QR/-X TRANSISTOR
Q2054 or 2SA1530A/QR/-X TRANSISTOR
Q2055 DTC144WKA-X DIGI TRANSISTOR
Q2055 or UN221E-X TRANSTSTOR
Q2055 or RT1N44HC-X DIGI TRANSISTOR
Q2201 DTA144WKA-X TRANSISTOR
Q2201 or UN211E-X DIGI TRANSISTOR
Q2201 or RT1P44HC-X DIGI TRANSISTOR
Q2202 DTC144WKA-X DIGI TRANSISTOR
Q2202 or UN221E-X TRANSTSTOR
Q2202 or RT1N44HC-X DIGI TRANSISTOR
Q2203
2SC2412K/QRS/-X
TRANSISTOR
Q2203 or 2SD601A/QRS/-X TRANSISTOR
Q2203 or
2SC3928A/QRS/-X
TRANSISTOR
Q2204
2SC2412K/QRS/-X
TRANSISTOR
Q2204 or 2SD601A/QRS/-X TRANSISTOR
Q2204 or
2SC3928A/QRS/-X
TRANSISTOR
Q2255 DTC114EKA-X DIGI TRANSISTOR
Q2255 or UN2211-X TRANSISTOR
Q2255 or RT1N141C-X DIGI TRANSISTOR
Q2601
2SC2412K/QRS/-X
TRANSISTOR
Q2601 or 2SD601A/QRS/-X TRANSISTOR
Q2601 or
2SC3928A/QRS/-X
TRANSISTOR
Q2602
2SC2412K/QRS/-X
TRANSISTOR
Q2602 or 2SD601A/QRS/-X TRANSISTOR
Q2602 or
2SC3928A/QRS/-X
TRANSISTOR
Q2603 DTA144WKA-X TRANSISTOR
Q2603 or UN211E-X DIGI TRANSISTOR
Q2603 or RT1P44HC-X DIGI TRANSISTOR
Q2604
2SC2412K/QRS/-X
TRANSISTOR
Q2604 or 2SD601A/QRS/-X TRANSISTOR
Q2604 or
2SC3928A/QRS/-X
TRANSISTOR
Q2605
2SC2412K/QRS/-X
TRANSISTOR
Q2605 or 2SD601A/QRS/-X TRANSISTOR
Q2605 or
2SC3928A/QRS/-X
TRANSISTOR
Q2606 DTA144WKA-X TRANSISTOR
Q2606 or UN211E-X DIGI TRANSISTOR
Q2606 or RT1P44HC-X DIGI TRANSISTOR
Q3002 PTZ-NV16A IC(PHOTO SENSOR
Q3003 PTZ-NV16A IC(PHOTO SENSOR
Q3004 2SD601A/QRS/-X TRANSISTOR
Q3004 or
2SC2412K/QRS/-X
TRANSISTOR
Q3004 or
2SC3928A/QRS/-X
TRANSISTOR
Q3005 2SD601A/QRS/-X TRANSISTOR
Q3005 or
2SC2412K/QRS/-X
TRANSISTOR
Q3005 or
2SC3928A/QRS/-X
TRANSISTOR
Q3007 UN221E-X TRANSTSTOR
Q3007 or DTC144WKA-X DIGI TRANSISTOR
Q3007 or RT1N44HC-X DIGI TRANSISTOR
Q3011 UN221L-X DIGI TRANSISTOR
Q3011 or DTC143EKA-X DIGI TRANSISTOR
Q3011 or RT1N431C-X DIGI TRANSISTOR
Q3901 UN221E-X TRANSTSTOR
Q3901 or DTC144WKA-X DIGI TRANSISTOR
Q3901 or RT1N44HC-X DIGI TRANSISTOR
Q4001 UN2211-X TRANSISTOR
Q4001 or DTC114EKA-X DIGI TRANSISTOR
Q4001 or RT1N141C-X DIGI TRANSISTOR
Q4201
2SC2412K/QRS/-X
TRANSISTOR
Q4201 or 2SD601A/QRS/-X TRANSISTOR
Q4201 or
2SC3928A/QRS/-X
TRANSISTOR
Q4302 2SA1037AK/QR/-X TRANSISTOR EF
Q4303 2SA1037AK/QR/-X TRANSISTOR EF
Q6001 2SD2144S/UV/-T TRANSISTOR
Q6030 2SA1037AK/QR/-X TRANSISTOR
Q6030 or 2SA1530A/QR/-X TRANSISTOR
Q7301
2SC2412K/QRS/-X
TRANSISTOR
Q7302 2SA720/RS/-T TRANSISTOR
D202 1SS133-T2 SI DIODE
D203 1SS133-T2 SI DIODE
D2001 1SS133-T2 SI DIODE
D2001 or 1SS270A-T2 SI DIODE
D2251 1SS133-T2 SI DIODE
D2251 or 1SS270A-T2 SI DIODE
Symbol No.
Part No. Part Name Description Local
After exchanging EEPROMs, a main part does not correspond to some remote control commands at Jig RCU mode.
Please cancel the Jig RCU mode of a main part after exchanging EEPROMs. Please refer to the "Canceling JIG mode"
about the release method.
To Next Page
