Terminal board
Block No. [0][6]
B7 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B9 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B13 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J EF
B202 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B501 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B503 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
B505 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
B7111 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B7112 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B7113 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B7114 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B7502 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
CN1 QGF1201C2-09 CONNECTOR FFC/FPC (1-9)
CN501 QGF1207C1-04 CONNECTOR FFC/FPC (1-4)
CN2001 QGF1207C1-06 CONNECTOR FFC/FPC (1-6)
CN2002 QGB2532J1-02 CONNECTOR B-B (1-2)
CN2601 QGB1231L1-11 CONNECTOR B-B (1-11)
CN3001 QGB2032M4-12 CONNECTOR B-B (1-12)
CN3102 QGF1207C1-15 CONNECTOR FFC/FPC (1-15)
CN3103 QGB1231L1-19 CONNECTOR B-B (1-19)
CN3901 QGF1207C1-06 CONNECTOR FFC/FPC (1-6)
CN4401 LPA10291-01B RGB_YC BOARD ASSY
CN5311 QGF1207C1-15 CONNECTOR FFC/FPC (1-15)
CN6701 LPA10292-04A DEMOD BOARD ASSY EF
CN7111 QGF1207C1-13 CONNECTOR FFC/FPC (1-13)
CN7112 QGF1207C1-09 CONNECTOR FFC/FPC (1-9)
CN7113 QGB2024K1-13S CONNECTOR B-B (1-13)
CN7114 QGB2024K1-15S CONNECTOR B-B (1-15)
CN7115 QGB2024K1-17S CONNECTOR B-B (1-17)
CN7119 LPA10011-03A SECAM BOARD ASSY EF
 CP3002 QMFZ050-1R25X-E FUSE 1.25A 125V
 CP4002 QMFZ050-1R25X-E FUSE 1.25A 125V
J7009 QNN0096-001 PIN JACK COAX OUT
J7301 QNS0259-001 3.5 JACK G-LINK
JS3001 NSW0238-001 ROTARY ENCODER
K2001 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K2002 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K2003 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K2004 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K2251 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K2252 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K7501 NQR0147-004X FERRITE BEADS
K7503 NQR0147-004X FERRITE BEADS
S3001 QSW0602-004 PUSH SWITCH REC SAFE
TU6001 QAU0402-002 TUNER EF
TU6001 QAU0401-001 TUNER E,EK
W1 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W2 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W3 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W4 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W5 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W6 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W7 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W8 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W9 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W10 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W14 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W15 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W16 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W17 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W18 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W19 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W20 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W21 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W22 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W23 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W24 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W25 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W26 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W27 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W28 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W29 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W30 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W31 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W32 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W33 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W34 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W35 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
W36 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W37 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W38 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W39 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W41 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W42 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W44 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W45 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W46 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W47 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W48 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W49 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W50 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W51 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W52 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W53 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W54 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W55 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W56 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W57 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W58 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
WR2 QRE141J-0R0Z C RESISTOR 0
Ω 1/4W J
X1 QAX0740-001 CRYSTAL 4.433619MHz
X3001 QAX0444-001 CRYSTAL 32.768kHz
X3002 QAX0527-001 CRYSTAL 10.000000MHz
X4201 QAX0849-001 CRYSTAL 4.433619MHz
OT1 LP31158-001A BOSS(MECHA) 1
OT2 LP31185-001A BOSS(MECHA) 2 (x2)
SD1 LP31179-001A SHILD PLATE(PRE/REC)
 Symbol No. Part No. Part Name Description Local
PW1 LPA10296-01B TERMINAL BOARD ASSY
IC901 HA118226F IC
IC902 BA7623F-X IC
Q901 2SC2412K/QRS/-X TRANSISTOR
Q901 or 2SD601A/QRS/-X TRANSISTOR
Q901 or 2SC3928A/QRS/-X TRANSISTOR
Q902 2SC2412K/QRS/-X TRANSISTOR
Q902 or 2SD601A/QRS/-X TRANSISTOR
Q902 or
2SC3928A/QRS/-X TRANSISTOR
Q903 DTC144WKA-X DIGI TRANSISTOR
Q903 or UN221E-X TRANSTSTOR
Q903 or RT1N44HC-X DIGI TRANSISTOR
Q904 DTC144WKA-X DIGI TRANSISTOR
Q904 or UN221E-X TRANSTSTOR
Q904 or RT1N44HC-X DIGI TRANSISTOR
Q905 DTC124XKA-X DIGI TRANSISTOR
Q905 or UN221T-X DIGI TRANSISTOR
Q905 or RT1N242C-X DIGI TRANSISTOR
Q907 2SA1037AK/QR/-X TRANSISTOR
Q907 or 2SB709A/QR/-X TRANSISTOR
Q907 or 2SA1530A/QR/-X TRANSISTOR
Q908 2SA1037AK/QR/-X TRANSISTOR
Q908 or 2SB709A/QR/-X TRANSISTOR
Q908 or 2SA1530A/QR/-X TRANSISTOR
Q912 2SA1037AK/QR/-X TRANSISTOR
Q913 2SA1037AK/QR/-X TRANSISTOR
Q932 2SA1037AK/QR/-X TRANSISTOR
Q932 or 2SB709A/QR/-X TRANSISTOR
Q932 or 2SA1530A/QR/-X TRANSISTOR
Q933 2SA1037AK/QR/-X TRANSISTOR
Q933 or 2SB709A/QR/-X TRANSISTOR
Q933 or 2SA1530A/QR/-X TRANSISTOR
Q936 2SA1037AK/QR/-X TRANSISTOR
Q936 or 2SB709A/QR/-X TRANSISTOR
Q936 or 2SA1530A/QR/-X TRANSISTOR
Q941 2SA1037AK/QR/-X TRANSISTOR
Q942 DTC114TKA-X TRANSISTOR
Q943 DTC144WKA-X DIGI TRANSISTOR
