3-22(No.YD084)
Loading Motor board
Block No. [5][5]
RGB_YC Converter board
Block No. [6][8]
Secam board
Block No. [8][8]
K1016 NQR0022-002X FERRITE BEADS
K1019 NQR0022-005X FERRITE BEADS
K1020 NQR0022-005X FERRITE BEADS
K1021 NQR0022-002X FERRITE BEADS
K1022 NQR0022-005X FERRITE BEADS
K1023 NQR0022-002X FERRITE BEADS
K1024 NQR0022-002X FERRITE BEADS
K1025 NQR0022-002X FERRITE BEADS
K1026 NQR0022-002X FERRITE BEADS
K1027 NQR0022-002X FERRITE BEADS
K1029 NQR0022-002X FERRITE BEADS
K1030 NQR0022-002X FERRITE BEADS
K1404 NQR0564-001X FERRITE BEADS
K1406 NQR0564-001X FERRITE BEADS
K1701 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K1702 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K1801 NQR0564-001X FERRITE BEADS
K1803 NQR0564-001X FERRITE BEADS
K2101 NQR0022-002X FERRITE BEADS
K2102 NQR0022-002X FERRITE BEADS
K2103 NQR0022-002X FERRITE BEADS
K2104 NQR0022-002X FERRITE BEADS
K2105 NQR0022-002X FERRITE BEADS
K2106 NQR0022-002X FERRITE BEADS
K2107 NQR0022-002X FERRITE BEADS
K2108 NQR0022-002X FERRITE BEADS
K2109 NQR0022-002X FERRITE BEADS
K2110 NQR0022-002X FERRITE BEADS
K2111 NQR0022-002X FERRITE BEADS
K2112 NQR0022-002X FERRITE BEADS
K2113 NQR0022-002X FERRITE BEADS
K2114 NQR0022-002X FERRITE BEADS
K2115 NQR0022-002X FERRITE BEADS
K2116 NQR0022-002X FERRITE BEADS
K2117 NQR0022-002X FERRITE BEADS
K2118 NQR0022-002X FERRITE BEADS
K2119 NQR0022-002X FERRITE BEADS
K2120 NQR0022-002X FERRITE BEADS
K2121 NQR0022-002X FERRITE BEADS
K2201 NQR0022-002X FERRITE BEADS
K2202 NQR0022-002X FERRITE BEADS
K2203 NQR0022-002X FERRITE BEADS
K2204 NQR0022-002X FERRITE BEADS
K2205 NQR0022-002X FERRITE BEADS
K2206 NQR0022-002X FERRITE BEADS
K2207 NQR0022-002X FERRITE BEADS
K2208 NQR0022-002X FERRITE BEADS
K2209 NQR0022-002X FERRITE BEADS
K2210 NQR0022-002X FERRITE BEADS
K2211 NQR0022-002X FERRITE BEADS
K2212 NQR0022-002X FERRITE BEADS
K2213 NQR0022-002X FERRITE BEADS
K2214 NQR0022-002X FERRITE BEADS
K2215 NQR0022-002X FERRITE BEADS
K2216 NQR0022-002X FERRITE BEADS
K2217 NQR0022-002X FERRITE BEADS
K2218 NQR0022-002X FERRITE BEADS
K2219 NQR0022-002X FERRITE BEADS
K2220 NQR0022-002X FERRITE BEADS
K2221 NQR0022-002X FERRITE BEADS
LC1401 NQR0512-008X EMI FILTER
LC1402 NQR0512-008X EMI FILTER
LC1403 NQR0512-008X EMI FILTER
X1301 NAX0733-001X CRYSTAL 14.31818MHz
X1402 NAX0768-001X CRYSTAL 13.5MHz
X1801 NAX0666-001X CRYSTAL 24.576000MHz
Symbol No.
Part No. Part Name Description Local
PW1 LPA10158-01A2 LOADING MOTOR BOARD ASSY
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
PW1 LPA10291-01B RGB_YC CONVERTER BOARD ASSY
IC4401 BH7236AF-X IC
IC4402 MM1503XN-X IC
IC4403 74HC4538D-X IC
IC4404 BA7666FS-X IC
D4401 RB717F-X SB DIODE
C4401 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C4403 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4404 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4405 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4406 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4407 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4408 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
C4409 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C4410 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C4411 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4412 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4413 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4417 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4418 NDC21HJ-103X C CAPACITOR 0.01uF 50V J
C4419 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C4420 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C4421 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4422 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4423 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4424 NCB30JK-105X C CAPACITOR 1uF 6.3V K
R4401 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R4402 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R4403 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4404 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4405 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4411 NRSA63D-204X MG RESISTOR 200k
Ω
1/16W D
R4412 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R4413 NRSA63D-753X MG RESISTOR 75k
Ω
1/16W D
R4414 NRSA63J-225X MG RESISTOR 2.2M
Ω
1/16W J
R4415 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R4416 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R4417 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R4418 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R4419 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R4420 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
CN4402 QGG2502K1-12 CONNECTOR (1-12)
OT1 LP40425-001A BRACKET(PWB)
Symbol No.
Part No. Part Name Description Local
PW1 LPA10011-03A SECAM BOARD ASSY EF
IC301 LA7358-E IC EF
Q301 2SB1218A/QR/-X TRANSISTOR EF
Q301 or 2SA1576A/QR/-X TRANSISTOR EF
Q301 or 2PA1576/R/-X TRANSISTOR EF
Q302 UN511E-X DIGI TRANSISTOR EF
Q302 or DTA144WUA-X DIGI TRANSISTOR EF
Q302 or PDTA144WU-X DIGI TRANSISTOR EF
C301 NDC21HJ-151X C CAPACITOR 150pF 50V J EF
C302 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M EF
C303 NCB21HK-682X C CAPACITOR 6800pF 50V K EF
To Next Page
