3-8
FS-SD990/FS-SD770
FS-SD550
Item
Parts number Parts name Area
Electrical parts list(Main board)
Remarks
Block No. 01
A
R1933 NRSA02J-681X MG RESISTOR CD6.5
R1934 NRSA02J-152X MG RESISTOR CD6.5
R1935 NRSA02J-272X MG RESISTOR CD6.5
R1936 NRSA02J-151X MG RESISTOR CD6.5
R1937 NRSA02J-562X MG RESISTOR
R1938 NRSA02J-102X MG RESISTOR
A
R3101 QRE141J-432Y C RESISTOR IN
R3102 QRE141J-103Y C RESISTOR IN
R3103 QRE141J-2R2Y C RESISTOR OUT
R3104 QRE141J-2R2Y C RESISTOR OUT
R3105 NRSA02J-223X MG RESISTOR AHB NF
R3106 NRSA02J-223X MG RESISTOR AHB NF
R3107 QRE141J-222Y C RESISTOR S.MUTE
R3201 QRE141J-432Y C RESISTOR IN
R3202 QRE141J-103Y C RESISTOR IN
R3203 QRE141J-2R2Y C RESISTOR OUT
R3204 QRE141J-2R2Y C RESISTOR OUT
R3205 NRSA02J-223X MG RESISTOR AHB NF
R3206 NRSA02J-223X MG RESISTOR AHB NF
R3207 QRE141J-222Y C RESISTOR S.MUTE
R3303 QRE141J-103Y C RESISTOR ST.BY
R3304 NRSA02J-682X MG RESISTOR AHB NF
R3305 NRSA02J-682X MG RESISTOR AHB NF
R8001 NRSA02J-102X MG RESISTOR
R8002 NRSA02J-103X MG RESISTOR
R8003 NRSA02J-331X MG RESISTOR
R8004 NRSA02J-331X MG RESISTOR
R8005 NRSA02J-561X MG RESISTOR
R8007 NRSA02J-432X MG RESISTOR
R8010 NRSA02J-104X MG RESISTOR
R8021 NRSA02J-391X MG RESISTOR FS-SD990
R8021 NRSA02J-101X MG RESISTOR FS-SD770/SD550
R8022 NRSA02J-101X MG RESISTOR FS-SD770/SD550
R8022 NRSA02J-391X MG RESISTOR FS-SD990
R8031 NRSA02J-561X MG RESISTOR FS-SD990
R8031 NRSA02J-431X MG RESISTOR FS-SD770/SD550
R8032 NRSA02J-431X MG RESISTOR FS-SD770/SD550
R8032 NRSA02J-561X MG RESISTOR FS-SD990
R8051 NRSA02J-101X MG RESISTOR
R8052 NRSA02J-272X MG RESISTOR
R8053 NRSA02J-332X MG RESISTOR
R8054 NRSA02J-562X MG RESISTOR
R8055 NRSA02J-123X MG RESISTOR
R8056 NRSA02J-393X MG RESISTOR
R8057 NRSA02J-101X MG RESISTOR
R8058 NRSA02J-272X MG RESISTOR
R8059 NRSA02J-332X MG RESISTOR
R8060 NRSA02J-562X MG RESISTOR
R8061 NRSA02J-123X MG RESISTOR
R8062 NRSA02J-393X MG RESISTOR
R8101 NRSA02J-220X MG RESISTOR
R8102 NRSA02J-222X MG RESISTOR
R8103 NRSA02J-272X MG RESISTOR
R8201 NRSA02J-220X MG RESISTOR
R8202 NRSA02J-222X MG RESISTOR
R8203 NRSA02J-272X MG RESISTOR
R8301 NRSA02J-222X MG RESISTOR
R8302 NRSA02J-222X MG RESISTOR
S8001 QSW0683-001Z PUSH SWITCH OP/CL
S8002 QSW0683-001Z PUSH SWITCH POWER
S8003 QSW0683-001Z PUSH SWITCH VOL+
S8004 QSW0683-001Z PUSH SWITCH VOL-
S8005 QSW0683-001Z PUSH SWITCH TIMER
S8006 QSW0683-001Z PUSH SWITCH CLOCK
S8007 QSW0683-001Z PUSH SWITCH UP
S8008 QSW0683-001Z PUSH SWITCH CD
S8009 QSW0683-001Z PUSH SWITCH STOP
S8010 QSW0683-001Z PUSH SWITCH DOWN
S8011 QSW0683-001Z PUSH SWITCH AHB
S8012 QSW0683-001Z PUSH SWITCH PRESET TU
S8013 QSW0683-001Z PUSH SWITCH TUNER
S8014 QSW0683-001Z PUSH SWITCH AUX
T 1 QQR0793-001 IFT
TU 1 QAU0097-001 FRONT END FM TU
X 1 QAX0402-001 CRYSTAL
Z1901 QNG0003-001Z FUSE CLIP
A
FOR F1901
Z1902 QNG0003-001Z FUSE CLIP
A
FOR F1901
Z1903 QNG0003-001Z FUSE CLIP
A
FOR F1902
Z1904 QNG0003-001Z FUSE CLIP
A
FOR F1902
Z1905 QNG0003-001Z FUSE CLIP
A
FOR F1903
Z1906 QNG0003-001Z FUSE CLIP
A
FOR F1903
Item
Parts number Parts name Area
Remarks
A
