JVC FS-SD990 - Page 40

3-10
FS-SD990/FS-SD770
FS-SD550
Item
Parts number Parts name Area
Electrical parts list(CD board)
Remarks
Block No. 02
A
D6062 1SS355-X DIODE
D6063 1SS355-X DIODE
D6500 MTZJ8.2B-T2 DIODE
D7001 1SS355-X DIODE
D7002 1SS355-X DIODE
D7003 1SS133-T2 SI DIODE
D7004 1SS133-T2 SI DIODE
D7005 1SS133-T2 SI DIODE
D7006 1SS355-X DIODE
D7007 MTZJ5.1C-T2 ZENER DIODE
D7008 1SS133-T2 SI DIODE
D7009 MTZJ8.2B-T2 DIODE
D7010 1SS355-X DIODE
IC501 BD3861FS-X IC FUNC/VOL
IC601 AN22000A IC
IC602 LA6541-X IC
IC603 MN662748RPMFA IC
IC701 UPD780024AGKB19 IC
IC702 KIA78S06P-T IC
J5301 QNS0047-001 JACK LINE IN
J5302 QNS0047-001 JACK LINE OUT
J5303 QNN0198-001 1PIN PINJ BLACK S.W. OUT
J6001 GP1FA550TZ OPT TRANSMITTER
K5302 QQR0601-001Z FERRITE BEADS DG
K6051 QQR0601-001Z FERRITE BEADS
K7001 QQR0601-001Z FERRITE BEADS
L7001 QQL244K-100Z INDUCTOR
L7002 QQL244K-100Z INDUCTOR
PP501 QZW0038-001 WIRE CLAMP
Q
5101 2SD2114K/VW/-X CHIP TRANSISTOR L/O MUTE
Q
5201 2SD2114K/VW/-X CHIP TRANSISTOR L/O MUTE
Q
5301 DTA114EKA-X DIGITAL.TRANSIS L/O MUTE.D
Q
5302 2SD2114K/VW/-X CHIP TRANSISTOR S.W.MUTE
Q
6001 2SA1037AK/R/-X TRANSISTOR
Q
6031 2SC2060/QR/-T TRANSISTOR
Q
6500 DTD123TK-X CHIP D.TR
Q
7001 2SC2814/4-5/-X TRANSISTOR
Q
7002 2SC2814/4-5/-X TRANSISTOR
Q
7003 DTA114TKA-X DIGITAL.TR
Q
7004 2SC2412K/R/-X TRANSISTOR
Q
7006 2SC2412K/R/-X TRANSISTOR
Q
7007 DTC114EKA-X TRANSISTOR
Q
7008 DTA114EKA-X DIGITAL.TRANSIS
Q
7009 2SA1037AK/R/-X TRANSISTOR
Q
7010 DTC144EKA-X TRANSISTOR
Q
7011 2SA1037AK/R/-X TRANSISTOR
R5101 NRSA63J-223X MG RESISTOR LINE IN
R5102 NRSA63J-683X MG RESISTOR LINE IN
R5103 NRSA63J-302X MG RESISTOR CD IN
R5104 NRSA63J-182X MG RESISTOR FUC.OUT
R5105 NRSA63J-473X MG RESISTOR LINE OUT
R5106 NRSA63J-392X MG RESISTOR LINE OUT
R5107 NRSA63J-102X MG RESISTOR LINE OUT
R5108 NRSA63J-222X MG RESISTOR L/O MUTE
R5109 NRSA63J-563X MG RESISTOR S.W.OUT
R5110 NRSA63J-332X MG RESISTOR BASS
R5201 NRSA63J-223X MG RESISTOR LINE IN
R5202 NRSA63J-683X MG RESISTOR LINE IN
R5203 NRSA63J-302X MG RESISTOR CD IN
R5204 NRSA63J-182X MG RESISTOR FUC.OUT
R5205 NRSA63J-473X MG RESISTOR LINE OUT
R5206 NRSA63J-392X MG RESISTOR LINE OUT
R5207 NRSA63J-102X MG RESISTOR LINE OUT
R5208 NRSA63J-222X MG RESISTOR L/O MUTE
R5209 NRSA63J-563X MG RESISTOR S.W.OUT
R5210 NRSA63J-332X MG RESISTOR BASS
R5301 NRSA63J-223X MG RESISTOR L/O MUTE D
R5302 NRSA63J-222X MG RESISTOR S.W.MUTE
R5303 NRSA63J-473X MG RESISTOR S.W.OUT
R5304 NRSA63J-102X MG RESISTOR S.W.OUT
R5305 NRSA63J-1R5X MG RESISTOR VCC
R6001 NRSA63J-682X MG RESISTOR
R6005 NRSA63J-184X MG RESISTOR
R6006 NRSA63J-274X MG RESISTOR
R6007 NRSA63J-393X MG RESISTOR
R6008 NRSA63J-394X MG RESISTOR
R6009 NRSA63J-473X MG RESISTOR
R6010 NRSA63J-154X MG RESISTOR
R6012 NRSA63J-822X MG RESISTOR
R6013 NRSA63J-121X MG RESISTOR
R6014 NRSA63J-100X MG RESISTOR
R6015 NRSA63J-120X MG RESISTOR
R6016 NRSA63J-910X MG RESISTOR
R6021 NRSA63J-330X MG RESISTOR
R6024 NRSA63J-103X MG RESISTOR
R6025 NRSA63J-103X MG RESISTOR
R6026 NRSA63J-222X MG RESISTOR
R6028 NRSA63J-222X MG RESISTOR
R6031 NRSA63J-102X MG RESISTOR
R6032 NRSA63J-102X MG RESISTOR
R6033 NRSA63J-102X MG RESISTOR
R6040 NRSA63J-102X MG RESISTOR
R6041 NRSA63J-184X MG RESISTOR
R6042 NRSA63J-472X MG RESISTOR
R6043 NRSA63J-912X MG RESISTOR
R6044 NRSA63J-393X MG RESISTOR
R6045 NRSA63J-433X MG RESISTOR
R6046 NRSA63J-392X MG RESISTOR
R6047 NRSA63J-472X MG RESISTOR
R6048 NRSA63J-272X MG RESISTOR
R6050 NRSA63J-332X MG RESISTOR
R6051 NRSA63J-102X MG RESISTOR
R6052 NRSA63J-102X MG RESISTOR
R6053 NRSA63J-101X MG RESISTOR
R6054 NRSA63J-102X MG RESISTOR
R6056 NRSA63J-0R0X MG RESISTOR
R6057 NRSA63J-0R0X MG RESISTOR
R6058 NRSA63J-0R0X MG RESISTOR
R6059 NRSA63J-471X MG RESISTOR
R6060 NRSA63J-471X MG RESISTOR
R6061 NRSA63J-104X MG RESISTOR
R6063 NRSA63J-124X MG RESISTOR
R6064 NRSA63J-331X MG RESISTOR
R6066 NRSA63J-470X MG RESISTOR
R6067 NRSA63J-220X MG RESISTOR
R6068 NRSA63J-220X MG RESISTOR
R6069 NRSA63J-155X MG RESISTOR
R6071 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R6072 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R6201 NRSA63J-472X MG RESISTOR
R6202 NRSA63J-222X MG RESISTOR
R6203 NRSA63J-0R0X MG RESISTOR
R6204 NRSA63J-623X MG RESISTOR
R6205 NRSA63J-393X MG RESISTOR
R6251 NRSA63J-102X MG RESISTOR
R6252 NRSA63J-105X MG RESISTOR
Item
Parts number Parts name Area
Remarks
A
