1 • MENU Wheel [–, +] ........................................... pg. 18
• BRIGHT Wheel [–, +]*
1
...................................... pg. 11
• TRACKING Wheel [–, +] ................................... pg. 14
2 • Snapshot Button [SNAPSHOT]*
2
...................... pg. 12
• 5-Second Recording Button
[5 SEC. REC]*
3
................................................. pg. 12
3 • Power Zoom Lever [T/W] .................................. pg. 13
• Speaker Volume Control [VOL.]*
1
...................... pg. 11
4 • Picture Stabilizer Button
[P.STABILIZER] ................................................
pg. 12
• Time Base Corrector Button [TBC] ...................
pg. 14
5 S-Video Output Connectors [S]*
4
........................ pg. 15
6 Audio Output Connector [A] ................................ pg. 15
7 Video Output Connector [V] ................................ pg. 15
8 Battery Release Switch
[BATTERY RELEASE] ..........................................
pg. 6
9 DC IN Connector .................................................. pg. 6
0 Digital Connector [DIGITAL]*
5
! Recording Start/Stop Button ................................ pg. 11
@ Power Switch [ , OFF, , ] .................... pg. 11
# Video Light Switch
[LIGHT OFF/AUTO/ON] ......................................
pg. 13
$ Stop Button [STOP] ............................................. pg. 11
% • Retake Rewind Button [RETAKE R] ................. pg. 13
• Quick Review Button [
R]............................ pg. 13
• Rewind Button [R] ..............................................
pg. 11
^ Play/Pause Button ............................................... pg. 11
& • Retake Forward Button [RETAKE F] ................ pg. 13
• Fast-Forward Button [F] .....................................
pg. 11
* CHARGE Lamp .................................................... pg. 6
( POWER/REFRESH Lamp .................................... pg. 6
) • Fade/Wipe Button [FADE/WIPE] ...................... pg. 22
• Counter Reset/Memory Button
[COUNTER R/M] ..............................................
pg. 14
q Program AE Button [P.AE] .................................. pg. 23
w Digital Effect Button [DIGIFECT]......................... pg. 23
e NIGHT-ALIVE Button*
2
........................................ pg. 22
r REFRESH Button ................................................. pg. 6
t EJECT Switch ....................................................... pg. 8
y Shoulder Strap Eyelets ......................................... pg. 8
u Battery Pack Mount ............................................... pg. 6
i Close Button ......................................................... pg. 8
o Diopter Adjustment Control ................................... pg. 8
p • Camera Sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
• Remote Sensor*
6
.......................................... pg. 9, 17
Q Grip Strap ............................................................. pg. 8
W Tripod Mounting Socket ........................................ pg. 8
E Infrared Beam Transmitting Window ............... pg. 9, 17
R ZOOM (T/W) Buttons .................................... pg. 13, 24
T PLAY Button ......................................................... pg. 11
Y REW Button (Functions the same as %)
U STOP Button (Functions the same as $)
I INSERT Button ................................................... pg. 24
O • REC TIME Button ............................................. pg. 24
• ANIM. Button ....................................................
pg. 24
P START/STOP Button (Functions the same as 0)
a FF Button (Functions the same as &)
s PAUSE Button...................................................... pg. 11
d A.DUB Button...................................................... pg. 24
f • INT.TIME Button ............................................... pg. 24
• SELF TIMER Button (non-functional)
1 Tape Remaining Time ......................................... pg. 21
2 Recording Mode Indicator ................................... pg. 20
3 • Digital Effect Indicator ....................................... pg. 23
• Program AE Indicator........................................
pg. 23
• Night-Alive Indicator*
2
....................................... pg. 22
• Fade/Wipe-Standby Indicator ...........................
pg. 22
4 Recording Format Indicator (S/S-ET)*
4
............... pg. 20
5 Tape Length Indicator ......................................... pg. 21
6 Zoom Indicator Bar ............................................. pg. 13
Zoom Level Indicator
Approximate Zoom Ratio
7 Recording Indicator .............................................. pg. 11
8 Digital Effect Indicator ......................................... pg. 23
9 • Program AE Indicator........................................ pg. 23
• Night-Alive Indicator*
2
....................................... pg. 22
0 Fade/Wipe-Standby Indicator ............................. pg. 22
! Picture Stabilizer Indicator .................................. pg. 12
@ • Interval Time/Recording Time Indicator ............... pg. 21
• 5 Sec. Rec Mode Indicator*
3
............................. pg. 12
# Bright Level Indicator*
1
......................................... pg. 11
$ Instant Title Display ............................................. pg. 19
% Date/Time Display ............................................... pg. 19
^ Focus Indicator ................................................... pg. 18
& Exposure Control Level Counter ......................... pg. 18
* White Balance Mode Indicator ............................ pg. 19
( S-VHS/S-VHS ET Recording
Indicator*
4
............................................................ pg. 20
) Record-Standby Mode Indicator .......................... pg. 11
q • : Cassette Indicator...................................... pg. 8
• w: Insert Editing Indicator*
6
.............................. pg. 24
w TBC Indicator ...................................................... pg. 14
e Playback Special Effect Indicator*
2
..................... pg. 14
r Recording Format Indicator (S/S-ET)*
4
............... pg. 20
t Tape Counter ................................................ pg. 14, 24
y Recording Mode Indicator (SP/EP) ..................... pg. 20
u Tape Running Indicator
4
: Playback
3
: Fast-Forward/Shuttle Search
2
: Rewind/Shuttle Search
6 : Pause
e
4
: Audio Dubbing*
6
i Tracking Indicator ............................................... pg. 14
o Tape Counter*
6
.................................................... pg. 24
p • BRIGHT: Bright Level Indicator*
1
....................... pg. 11
• VOLUME: Speaker Volume Indicator*
1
............... pg. 11
*
1
Applicable models only.
*
2
GR-SXM740/SXM540/SXM340 only.
*
3
GR-AXM240/SX970 only.
*
4
GR-SXM740/SXM540/SXM340/SX970 only.
*
5
GR-SXM740/SXM540 only.
*
6
GR-SXM740 only.
