(No.86730)1-11
Fig.D3
4
(S3a)
5
(S3a)
L3
PREMDA BOARD ASSEMBLY
6
(S3b)
7
(S3b)
9
(S4)
0.069N
.
m (0.7kgf
.
cm)
0.078N
.
m (0.8kgf
.
cm)
8
(S4)
(PR)
SHIELD COVER
[4]
BKT(MECHA)
CN3a
CN3b
CN3c
CN3e
CN3f
CN3d
[3]
10
(S4)
