(No.YF079)3-7
2. PARTS LIST
FINAL ASSEMBLY <M1>
MECHANISM ASSEMBLY <M2>
VF(COLOR) ASSEMBLY <M3>
Symbol No.
Part No. Part Name Description Local
103 LY34543-001C FRAME(Z27)ASSY
103A LY45033-001A BUSH (x3)
105 LY34542-001A S.COVER(PR)
106 LY21323-004F REAR UNIT
107 LY34567-003D T.COVER ASSY
108 LY30031-015A SPECIAL SCREW
MC-PRE/MDA(x2)
109 LY30031-015A SPECIAL SCREW MCHA-SHLD(x2)
110 LY30032-002A SPECIAL SCREW FRM-MCA(x3)
111 LY30031-0H2B SPECIAL SCREW FRM-MAIN
112 LY30031-0H2B SPECIAL SCREW FRM-FRNT
113 LY30031-0D4A SPECIAL SCREW FRM-BKT(AR)
114 LY30031-0D4A SPECIAL SCREW LOWER-REAR
115 LY30031-0H2B SPECIAL SCREW FRM-VF
116 LY30031-0H2B SPECIAL SCREW FRM-REAR
117 LY30031-0H5A SPECIAL SCREW VF-ZOOM(x2)
118 LY30031-0H2B SPECIAL SCREW FRM-UPPER
119 LY30031-0H5A SPECIAL SCREW VF-BKT(OPE)
120 LY30031-0D5A SPECIAL SCREW FRM-UPPER(x3)
121 LY30031-0D5A SPECIAL SCREW BK(HNG)-UP
122 LY30031-008A SPECIAL SCREW UPPER-REAR
123 LY30031-0H2B SPECIAL SCREW FRM-TOP
124 LY30031-0D5A SPECIAL SCREW VF-TOP
125 LY30031-008A SPECIAL SCREW REAR-TOP
133 LY30031-0D5A SPECIAL SCREW LOWER-FRM
134 LY34566-001B COVER(REAR 2)
136 LY30031-0D4A SPECIAL SCREW FRM-SHLD
201 LY34552-001B JACK COVER(REAR)
202 LY44931-002D COVER(JIG)ASSY
202A LY34661-001B C.LABEL(VF)
203 LY34569-001D COVER(ADJUST)
205 LY40699-002A LABEL(PUSH)
206 LY32001-004A LABEL(HOUSING)
300 LU05D203A LOWER UNIT ASSY JAPAN
301 LY21345-002E LOWER CASE ASSY
302 LY34540-001E ARM ASSY
303 QAS0284-001 SPEAKER
304 LY10548-001D ZOOM UNIT
305 LY10549-001C CASSETTE COVER
306 LY21320-001A GRIP BELT
307 LY44829-001A SHAFT(G.BELT)
308 LY30031-008A SPECIAL SCREW
LOWER-ARM(x3)
309 LY30031-008A SPECIAL SCREW
LOWER-ZOOM(x3)
310 LY30031-0H5A SPECIAL SCREW C.COV-ARM(x4)
502 LY34545-002F F.COVER ASSY
502A LY34546-001A HOOD(SCREW)
502B LY30031-034A SPECIAL SCREW (x4)
503 LY34598-001A MIC
504 LY34551-001B PLATE(MIC)
505 LY30031-003A SPECIAL SCREW (x2)
602 LY34620-001B OP BLOCK ASSY
602A PTY34620-002 FOCUS MOTOR UNIT
602B PTY34620-001 ZOOM MOTOR UNIT
602C PTY34620-006 AUTO IRIS UNIT
602D PTY34620-535 TAP SCREW
602E PTY34620-530 TAP SCREW (x6)
602F PTY34620-525 TAP SCREW (x2)
603 LY30031-038A SPECIAL SCREW (x2)
604 LY44893-001A SHEET
605 LY44927-001A O.LPF
606 LY34628-001A SPACER
607 LYH30605-001A CCD BASE ASSY
608 QUQ105-2404BA-E FFC WIRE 24pin 4cm
609 LY44831-001A BUSH(OP)
610 LY44159-001A WASHER (x2)
699 LY30034-0S5A SPACER(A)
Symbol No.
Part No. Part Name Description Local
900 YMA0029BG MECHA(A)ASSY Y/E Y08173
900A YMA0029AA MECHA(A)ASSY JVM/BJVC
901 LY32870-001Q CASSETTEHOUSING ASSY
902 YQ43893-8 MINI SCREW (x3)
903 LYH30420-001A UPPER BASE ASSY
904 QYSPSPU1425M SCREW M1.4 x 2.5mm
905 YDV2102E DRUM ASSY M/B SET022
906 LY44533-001A DAMP.SCREW ASSY JVM/BJVC(x2)
907 LY44533-002A DAMP.SCREW ASSY
908 LY31538-001G REEL DISK ASSY
909 LY31538-002J REEL DISK ASSY
910 YQ44246 SLIT WASHER (x2)
911 LY10372-001K REEL COVER ASSY
912 LY42120-002A MINI SCREW
913 LY41945-003A MINI SCREW (x2)
914 YQ44246 SLIT WASHER
915 LY43725-001G TENSION ARM ASSY
916 LYH40269-001A SLANT POLE ARM ASSY
917 LY43731-001G TAKE UP ARM ASSY
918 LY31531-001E SWING ARM ASSY
919 YQ43893-9 MINI SCREW
920 LYH30424-001A SLIDE DECK FINAL ASSY
921 YQ43893 MINI SCREW (x2)
922 LY43023-001A MINI SCREW
924 LYH30419-001A PAD ARM ASSY
925 YQ44246 SLIT WASHER
928 LYH40270-001A TAKE UP BRAKE ASSY
929 YQ44246 SLIT WASHER
930 LY43684-001C TENSION CONTROL LEVER ASSY
931 LY32861-001B CENTER GEAR
932 LY31516-001J PINCH ROLLER ARM FINAL ASSY
933 YQ44246 SLIT WASHER
934 LY43681-001B TENSION CONTROL PLATE ASSY
935 LY43687-001A BRAKE CONTROL LEVER ASSY
936 LYH30421-001A MOTOR BRACKET ASSY
937 YQ43893 MINI SCREW (x3)
938 LYH30422-001A GUIDE RAIL ASSY
939 YQ43893 MINI SCREW
940 YQ44246 SLIT WASHER (x2)
941 LY32843-001H SLIDE LEVER2 ASSY
942 LY43690-001C LOADING PLATE ASSY
943 YQ44246 SLIT WASHER
944 LY32858-001B EJECT LEVER
945 YQ44246 SLIT WASHER
946 LYH40271-001A BASE R ASSY
947 YQ43893 MINI SCREW
948 LY41945-001B MINI SCREW
949 LY43665-001A MODE GEAR
950 QSW0876-005 ROTARY ENCODER
951 YQ43893 MINI SCREW (x2)
952 LY32860-001E GEAR COVER ASSY
953 YQ43893 MINI SCREW (x2)
954 YQ43893-4 MINI SCREW
955 LY43676-001B MAIN CAM ASSY
956 LY41941-001B SLIDE ARM ASSY
957 LY43678-001A CONNECT GEAR 2
958 LY43679-001C SUB CAM ASSY
959 LY42120-001A MINI SCREW
960 LY43692-001B CONTROL ARM ASSY
961 LY32859-001A REEL GEAR 1
962 LY31508-003F DRUM BASE ASSY
963 LY43675-006B MINI SCREW (x3)
964 QAR0142-001 CAPSTAN MOTOR
965 YQ43893 MINI SCREW
966 LY10367-001N MAIN DECK ASSY
976 YQ44246 SLIT WASHER
978 LY44609-001A WASHER
979 LY44502-001A SPACER JVM/BJVC
998 QYWFM163013 WASHER
6.3mm/21.1mm x 0.01mm
Symbol No.
Part No. Part Name Description Local
700 VU05D201A VF UNIT ASSY JAPAN
702 LY21328-001C U.CASE(VF)
Symbol No.
Part No. Part Name Description Local
MODEL MARK
A
B
C
GR-D240EK
GR-D240EX
GR-D240EY
MODEL MARK
D
E
F
GR-D240EZ
GR-D245EG
GR-D247EK
