GETTING STARTED
MasterPage: Start_Right
GETTING STARTED
Controls
A Stop Button [8] (墌 pg. 20)
Backlight Compensation Button [BACK
LIGHT] (墌 pg. 33)
B Play/Pause Button [4/9] (墌 pg. 20)
Manual Focus Button [FOCUS] (墌 pg. 31)
C Rewind Button [ 3 ] (墌 pg. 20)
Menu select Button [–] (墌 pg. 14)
Quick Review Button [ ] (墌 pg. 19)
D Fast-Forward Button [ 5 ] (墌 pg. 20)
Menu select Button [+] (墌 pg. 14)
Night Button [NIGHT] (墌 pg. 30)
E Menu Button [MENU] (墌 pg. 24)
Data Battery Button [DATA] (墌 pg. 12)
F LED Light Button [LIGHT] (墌 pg. 30)
G Dioptre Adjustment Control (墌 pg. 15)
H Snapshot Button [SNAPSHOT] (墌 pg. 31)
I Power Zoom Lever [T/W] (墌 pg. 18)
Speaker Volume Control [VOL. +, –]
(墌 pg. 20)
J Battery Release Button [PUSH BATT.]
(墌 pg. 11)
K Recording Start/Stop Button (墌 pg. 17)
L Power Switch [A, M, PLAY, OFF] (墌 pg. 13)
M Lock Button (墌 pg. 13)
N Cassette Open/Eject Switch [OPEN/EJECT]
(墌 pg. 16)
Connectors
The connectors are located beneath the covers.
O S-Video/Audio/Video Output Connector [S/
AV] (墌 pg. 21, 37)
P DC Input Connector [DC] (墌 pg. 11)
Q Digital Video Connector [DV OUT] (i.Link*)
(墌 pg. 38, 39)
R Microphone connector [MIC] (墌 pg. 28)
(An optional microphone can be used during
video recording and audio dubbing. To
stabilise the microphone, use of an optional
shoe adapter is recommended.)
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
Indicators
S POWER/CHARGE Lamp (墌 pg. 11, 17)
Other Parts
T Monitor Latch (墌 pg. 18)
U LCD Monitor (墌 pg. 18, 19)
V Viewfinder (墌 pg. 15)
W Battery Pack Mount (墌 pg. 12)
X Shoulder Strap Eyelet (墌 pg. 11)
Y Speaker (墌 pg. 20)
Z Grip Strap (墌 pg. 14)
a Lens
b LED Light (墌 pg. 30)
(When using an optional conversion lens, it
may cover this area and block the light.)
c Camera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here.)
d Stereo Microphone
e Stud Hole (墌 pg. 15)
f Tripod Mounting Socket (墌 pg. 15)
g Cassette Holder Cover (墌 pg. 16)
