JVC GR-D33EK - VF(COLOR) ASSEMBLY <M4> [S TYPE]; VF(COLOR) ASSEMBLY <M4> [K TYPE]

3-10(No.YF008)
VF(COLOR) ASSEMBLY <M4> [S TYPE]
NOTE :
There are two types of VF(COLOR) ASSEMBLY used for this model:
S type and K type.
For methods to distinguish the two types, see Cover Page.
VF(COLOR) ASSEMBLY <M4> [K TYPE]
NOTE :
There are two types of VF(COLOR) ASSEMBLY used for this model:
S type and K type.
For methods to distinguish the two types, see Cover Page.
MONITOR ASSEMBLY <M5>
MAIN BOARD ASSEMBLY <01>
 Symbol No. Part No. Part Name Description Local
700 VU04D101C VF UNIT ASSY
701 LY33690-001C EYE CUP
702 LY43961-001B SHEET(LENS)
703 LY32472-001A LENS ASSY
703A LY43356-001A LENS(A)
703B LY43357-001A LENS(B)
704 LY33688-001A GUIDE LENS(VF)
705 LY21095-001C UPPER CASE(VF)
706 LY43960-001A CUSHION 2(LCD)
707 LY32997-001A SHEET HOLD(VF)
708 LY43953-001A SHEET 1(POLA)
709 LY33003-001C HOLDER LCD2(VF)
710 LY21094-001C BOTTOM CASE(VF)
711 QLD0266-001 LCD MODULE
712 LY43954-001A SHEET 2(POLA)
713 LY43959-001A SHEET 2(DIFF)
714 LY33004-001A LCD HOLD 2(VF)
715 LY33047-001A GUIDE(LCD)2
716 QAL0523-001 FPC VF-FPC
717 NSW0200-001X LEVER SWITCH TEZUKE
718 LY43868-001A SPRING(LENS)
719 LY33689-001C LEVER(LENS)
720 LY21096-001C HOLDER(VF)
721 LY33691-001A BRACKET(VF)
722 LY33692-001A SPRING(VF)
723 LY30031-016A SPECIAL SCREW PWB-BKT(x2)
724 LY30031-031A SPECIAL SCREW BC-UC(x2)
725 LY30031-030A SPECIAL SCREW BC-HLDLCD
726 LY30031-031A SPECIAL SCREW BC-GUID
727 LY30032-005A SPECIAL SCREW EYE-GUID(x2)
728 LY30031-026A SPECIAL SCREW SPR-LC
729 LY30031-016A SPECIAL SCREW HLDVF-BKT(x2)
730 LY30031-010A SPECIAL SCREW HLDVF-BKT
732 LY30030-0Y5A SPACER(A)
799 LY33722-001A LCD UNIT(COLOR)ASSY
 Symbol No. Part No. Part Name Description Local
700 VU04D102A VF UNIT ASSY
701 LY33690-001C EYE CUP
702 LY43961-001B SHEET(LENS)
703 LY32472-001A LENS ASSY
703A LY43356-001A LENS(A)
703B LY43357-001A LENS(B)
704 LY33688-001B GUIDE LENS(VF)
705 LY21095-001C UPPER CASE(VF)
706 LY43957-001A CUSHION(LCD)
707 LY32997-001A SHEET HOLD(VF)
708 LY43953-001A SHEET 1(POLA)
709 LY32994-001B HOLDER LCD(VF)
710 LY21094-001D BOTTOM CASE(VF)
711 QLD0306-001 LCD MODULE
712 LY43954-001A SHEET 2(POLA)
713 LY43955-001A SHEET (DIFF)
714 LY32998-001A LCD HOLD(VF)
715 LY33002-001B GUIDE(LCD)
716 QAL0523-001 FPC VF-FPC
717 NSW0200-001X LEVER SWITCH TEZUKE
718 LY43868-001A SPRING(LENS)
719 LY33689-001C LEVER(LENS)
720 LY21096-001C HOLDER(VF)
721 LY33691-001A BRACKET(VF)
722 LY33692-001A SPRING(VF)
723 LY30031-016A SPECIAL SCREW PWB-BKT(x2)
724 LY30031-031A SPECIAL SCREW BC-UC(x2)
725 LY30031-030A SPECIAL SCREW BC-HLDLCD
726 LY30031-031A SPECIAL SCREW BC-GUID
727 LY30032-005A SPECIAL SCREW EYE-GUID(x2)
728 LY30031-026A SPECIAL SCREW SPR-LC
729 LY30031-016A SPECIAL SCREW HLDVF-BKT(x2)
730 LY30031-010A SPECIAL SCREW HLDVF-BKT
732 LY30030-0Y5A SPACER(A)
799 LY33821-001A LCD UNIT ASSY
 Symbol No. Part No. Part Name Description Local
 800 MU04D103E MONITOR UNIT ASSY K,L,M,N
 800 MU04D104E MONITOR UNIT ASSY A,B,C,D,E,F,G,H,J
 802 LY21092-003F MONITOR COVER ASSY K,L,M,N
 802 LY21092-004F MONITOR COVER ASSY A,B,C,D,E,F,G,H,J
802A LY30030-0Z1B SPACER(A)
802B LY33680-001B KNOB(LOCK)M
802C LY33681-001B HOLDER(LOCK)M
802D LY30002-022A COMPRESION SPRING
802E LY30031-008A SPECIAL SCREW (x2)
802F LY44428-001C POP STICKER(1)
803 LY10471-001C MONITOR CASE
804 LY33683-001A LCD FRAME(MONI)
805 LY33969-001A SHIELD CASE ASSY
805A LY30030-0Z8A SPACER(A) FOR S.CASE
806 LY30033-001A SPECIAL SCREW(W) M.PWB-S.C
807 LY30031-010A SPECIAL SCREW MCOV-MCAS(x2) B
807 LY30031-0E2A SPECIAL SCREW MCOV-MCAS(x2) A,C,D,E,F,G,H,J,K,L,M,N
808 LY30031-013A SPECIAL SCREW MCOV-HING(x2)
809 LY33685-001B MONITOR HINGE ASSY
809A QAL0522-001 FPC MONI-FPC
809B LY33686-001B HINGE COVER(U)
809C LY33687-001B HINGE COVER(L)
809D LY30031-014A SPECIAL SCREW HINC.U-L(x2) K,L,M,N
809D LY30018-0K1A SPECIAL SCREW HINC.U-L(x2) A,B,C,D,E,F,G,H,J
810 LY44481-001A LIGHT SCREEN
811 QLL0142-001 LAMP
812 LY43936-001A HOLDER(LAMP) (x2)
813 LY33684-001A SHEET(DIFF.)
814 LY43396-001A SHEET(REFLECT)
815 QLD0294-001 LCD MODULE
816 LY44495-001D SHEET(MONI.)
 Symbol No. Part No. Part Name Description Local
PW1 YB10444D-03 MAIN BOARD ASSY F,G,H,J
PW1 YB10444E-03 MAIN BOARD ASSY K,L,M,N
PW1 YB10449B-02 MAIN BOARD ASSY A,B,C,D
PW1 YB10449E-02 MAIN BOARD ASSY E
IC1001 MN103S33NJS IC(MICRO C ROM) MASK A,B,C,D
IC1001 or MN103SF33NY4JS IC(MICRO C ROM) FLASH A,B,C,D
IC1001 MN103S33NJR IC(MICRO C ROM) MASK
E,F,G,H,J,K,L,M,N
IC1001 or MN103SF33NY4JR IC(MICRO C ROM) FLASH E,F,G,H,J,K,L,M,N
IC1002 MB90097PFV149-X IC(MICRO C ROM) MB90099
IC1003 SN74AHC1G00K-X IC
IC1003 or SN74AHC1G00DC-X IC
IC1004 NJU7108F3-X IC
IC1004 or TC75S56FU-X IC
IC1005 X25330S8I-2.5-X IC
IC1005 or AT25320N-10SI-X IC ATMEL
IC1005 or M95320-WMN6W-X IC ST MICRO
IC1005 or CAT25C32SI-X IC CATALYST
IC1006 RS5C314-X IC
IC1007 IC-PST3423U-X IC
IC1007 or S-80823CNNB-X IC
 Symbol No. Part No. Part Name Description Local
MODEL MARK
GR-D23EK
GR-D23EX
GR-D23EY
GR-D23EZ
A
B
C
D
MODEL MARK
GR-D33EK
GR-D53EK
GR-D53EX
GR-D53EY
E
F
G
H
MODEL MARK
GR-D53EZ
GR-D73EK
GR-D73EX
GR-D73EY
J
K
L
M
MODEL MARK
GR-D73EZ N
