JVC GR-D33EK - Page 122

(No.YF008)3-11
IC1101 BA10358F-XE IC W/B SENS
IC1101 or LM358DR-X IC W/B SENS
IC1151 RPM7138 IR DETECT UNIT IR SENS
IC1151 or RPM7138-S IR DETECT UNIT IR SENS
IC2101 AK5355VT-X IC F, G, H, J, K ,L ,M ,N
IC2201 AK4564VQ IC
IC3001 JCY0152 IC JCY0152
IC3002 BU2501FV-X IC
IC3005 JCY0136-X IC JCY0136-X
IC3201 JCP8075 IC
IC3701 BA7665AFS-X IC
IC3731 MM1504XN-X IC MM1504
F, G, H, J, K ,L ,M ,N
IC4201 HD49340NP-X IC
IC4202 MM1613AN-X IC
IC4301 JCY0200 IC
IC4802 LM324PW-X IC HALL AMP
IC4804 LM358AD-X IC DRIVE AMP
IC4804 or LM358AD623-X IC DRIVE AMP
IC4807 SN74AHC2G66U-X IC DUMP CUT K,L,M,N
IC4851 UPD16879GS-X IC F/Z_MDA
IC5501 JCY0185 IC
IC6001 FA3698F IC
IC6801 R1224N102G-X IC
IC8001 TMS320DSC24GHKL IC DSC24 F, G, H, J, K ,L ,M ,N
IC8002 K4S643232F-TC60 IC SDRAM F, G, H, J, K ,L ,M ,N
IC8002 or HY57643220CT55 IC SDRAM F, G, H, J, K ,L ,M ,N
IC8002 or HY57643220CT7 IC SDRAM F, G, H, J, K ,L ,M ,N
IC8003 MR27T1602F14DTN IC(MICRO C ROM) WRITE ONCE F, G, H, J, K ,L ,M ,N
IC8004 S-80842CNNB-W IC USB DET F, G, H, J, K ,L ,M ,N
IC8006 BU2360FV-X IC A.VCO W F, G, H, J, K ,L ,M ,N
IC8301 ISP1181ABS IC USB DRV F, G, H, J, K ,L ,M ,N
Q1001 DTA114EE-X DIGI TRANSISTOR
Q1001 or PDTA114EE-X DIGI TRANSISTOR
Q1001 or RN2102-X DIGI TRANSISTOR
Q1001 or BCR183T-X DIGI TRANSISTOR
Q1002 UMC3N-W DIGI TRANSISTOR
Q1003 UMC3N-W DIGI TRANSISTOR
Q1004 UMC3N-W DIGI TRANSISTOR
Q1005 DTC143XE-X DIGI TRANSISTOR
Q1006 DTC144EE-X DIGI TRANSISTOR
Q1006 or UN9213J-X DIGI TRANSISTOR
Q1006 or RN1104-X DIGI TRANSISTOR
Q1006 or PDTC144EE-X DIGI TRANSISTOR
Q1007 2SC4617/QR/-X TRANSISTOR
Q1007 or BC847BT-X TRANSISTOR
Q1008 DTC124EE-X DIGI TRANSISTOR
Q1008 or PDTC124EE-X DIGI TRANSISTOR
Q1008 or BCR141T-X DIGI TRANSISTOR
Q1009 2SJ347-X MOS FET
Q1010 DTC144EE-X DIGI TRANSISTOR
Q1010 or UN9213J-X DIGI TRANSISTOR
Q1010 or RN1104-X DIGI TRANSISTOR
Q1010 or PDTC144EE-X DIGI TRANSISTOR
Q1101 RPM-22PB PHOTO TRANSISTOR
Q2202 UMX1N-W PAIR TRANSISTOR
Q2202 or BC847S-X PAIR TRANSISTOR
Q2401 2SC4617/QR/-X TRANSISTOR
Q2401 or BC847BT-X TRANSISTOR
Q2403 2SC4617/QR/-X TRANSISTOR
Q2403 or BC847BT-X TRANSISTOR
Q3001 2SC4617/RS/-X TRANSISTOR
Q3001 or BC847BT-X TRANSISTOR
Q3002 2SC4617/RS/-X TRANSISTOR
Q3002 or BC847BT-X TRANSISTOR
Q3701 UMT1N-W PAIR TRANSISTOR
Q3701 or XP4401-W TRANSISTOR
Q3701 or BC856S-X PAIR TRANSISTOR
Q3702 BC847PN-X PAIR TRANSISTOR
Q3704 2SA1774/RS/-X TRANSISTOR
Q3704 or BC857BT-X TRANSISTOR
Q3705 UMT1N-W PAIR TRANSISTOR
Q3705 or XP4401-W TRANSISTOR
Q3705 or BC856S-X PAIR TRANSISTOR
Q3731 2SC4617/RS/-X TRANSISTOR F, G, H, J, K ,L ,M ,N
Q3731 or 2SD2216J/RS/-X TRANSISTOR F, G, H, J, K ,L ,M ,N
Q3731 or BC847BT-X TRANSISTOR F, G, H, J, K ,L ,M ,N
Q3732 DTC144EE-X DIGI TRANSISTOR F, G, H, J, K ,L ,M ,N
 Symbol No. Part No. Part Name Description Local
Q3732 or UN9213J-X DIGI TRANSISTOR F,G,H,J,K,L,M,N
Q3732 or BCR148T-X DIGI TRANSISTOR F,G,H,J,K,L,M,N
Q3733 BC847PN-X PAIR TRANSISTOR F,G,H,J,K,L,M,N
Q3734 2SC4617/RS/-X TRANSISTOR F,G,H,J,K,L,M,N
Q3734 or 2SD2216J/RS/-X TRANSISTOR F,G,H,J,K,L,M,N
Q3734 or BC847BT-X TRANSISTOR F,G,H,J,K,L,M,N
Q3735 BC847PN-X PAIR TRANSISTOR F,G,H,J,K,L,M,N
Q4801 2SC4655/BC/-X TRANSISTOR HALL DRIVE
Q4802 2SC4617/RS/-X TRANSISTOR 2SC4617/RS K,L,M,N
Q4802 or BC847BT-X TRANSISTOR K,L,M,N
Q4802 or 2SD2216J/RS/-X TRANSISTOR K,L,M,N
Q4803 DTC144EE-X DIGI TRANSISTOR DTC144EE K,L,M,N
Q4803 or BCR148T-X DIGI TRANSISTOR K,L,M,N
Q4804 DTA144EE-X DIGI TRANSISTOR DTA144EE K,L,M,N
Q4804 or BCR198T-X DIGI TRANSISTOR K,L,M,N
Q4805 DTA143EE-X DIGI TRANSISTOR DTA143EE K,L,M,N
Q4805 or BCR162T-X DIGI TRANSISTOR K,L,M,N
Q4806 2SC4617/QR/-X TRANSISTOR 2SC4617/QR
Q4806 or BC847BT-X TRANSISTOR
Q4806 or 2SD2216J/RS/-X TRANSISTOR 2SD2216J/R F,G,H,J,K,L,M,N
Q4851 2SC4617/RS/-X TRANSISTOR
Q4851 or BC847BT-X TRANSISTOR
Q6101 QS6U24-W MOS FET
Q6102 2SA1577/QR/-X TRANSISTOR
Q6102 or BC807-25W-X TRANSISTOR
Q6201 QS6U24-W MOS FET
Q6301 QS6U24-W MOS FET
Q6302 2SA1577/QR/-X TRANSISTOR
Q6302 or BC807-25W-X TRANSISTOR
Q6303 2SC4617/QR/-X TRANSISTOR
Q6303 or BC847BT-X TRANSISTOR
Q6401 QS6U24-W MOS FET
Q6501 QS6U24-W MOS FET
Q6601 SSM3J14T-X MOS FET
Q6603 2SA1577/QR/-X TRANSISTOR
Q6603 or BC807-25W-X TRANSISTOR
Q6604 DTC144EE-X DIGI TRANSISTOR
Q6604 or BCR148T-X DIGI TRANSISTOR
Q6605 UMT1N-W PAIR TRANSISTOR
Q6605 or HN1A01FU/G/-X PAIR TRANSISTOR
Q6605 or BC856S-X PAIR TRANSISTOR
Q6606 2SC4617/QR/-X TRANSISTOR
Q6606 or BC847BT-X TRANSISTOR
Q6701 SSM3J14T-X MOS FET
Q6801 FML9-W TRANSISTOR
Q8002 2SA1774/QR/-X TRANSISTOR USB DET W
F,G,H,J,K,L,M,N
Q8002 or BC857BT-X TRANSISTOR F,G,H,J,K,L,M,N
D1001 DA221-X DIODE ARRAY
D1001 or MA133-X SI DIODE
F,G,H,J,K,L,M,N
D3001 EC2C01C-TR-X VARI CAP DIODE
D3002 EC2C01C-TR-X VARI CAP DIODE
D3003 EC2C01C-TR-X VARI CAP DIODE
D3004 BAT165-X SB DIODE
D4301 MA2Z748-X SB DIODE
D5501 BAS16-03W-X SI DIODE
D6601 RB481K-X SB DIODE
D6602 RB480Y-W SB DIODE
D6701 RB160M-30-X SB DIODE
D6702 RB160M-30-X SB DIODE
 D6801 RB715F-X SB DIODE
 D6801 or BAS40-05W-X SB DIODE
D8001 BAS170W-X SB DIODE USB DET
F,G,H,J,K,L,M,N
C1001 NDCA1HJ-4R0W C CAPACITOR 4pF 50V J
C1002 NDCA1HJ-4R0W C CAPACITOR 4pF 50V J
C1004 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z
C1005 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z
C1007 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z
C1008 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z
C1009 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z
C1010 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z
C1011 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z
C1012 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z
C1013 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z
C1014 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z
C1015 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z
C1019 NCFA1HZ-103W C CAPACITOR 0.01uF 50V Z
 Symbol No. Part No. Part Name Description Local
MODEL MARK
GR-D23EK
GR-D23EX
GR-D23EY
GR-D23EZ
A
B
C
D
MODEL MARK
GR-D33EK
GR-D53EK
GR-D53EX
GR-D53EY
E
F
G
H
MODEL MARK
GR-D53EZ
GR-D73EK
GR-D73EX
GR-D73EY
J
K
L
M
MODEL MARK
GR-D73EZ N
