(No.YF008)3-19
Q7601 2SC4617/QR/-X TRANSISTOR
Q7601 or 2SC4738/YG/-X TRANSISTOR
Q7601 or 2SD2216J/QR/-X TRANSISTOR
Q7601 or BC847BT-X TRANSISTOR
Q7602 2SA1774/QR/-X TRANSISTOR
Q7602 or 2SA1832/YG/-X TRANSISTOR
Q7602 or BC857BT-X TRANSISTOR
Q7602 or 2SB1462J/QR/-X TRANSISTOR
Q7603 2SC4617/QR/-X TRANSISTOR
Q7603 or 2SC4738/YG/-X TRANSISTOR
Q7603 or 2SD2216J/QR/-X TRANSISTOR
Q7603 or BC847BT-X TRANSISTOR
Q7604 2SA1774/QR/-X TRANSISTOR
Q7604 or 2SA1832/YG/-X TRANSISTOR
Q7604 or BC857BT-X TRANSISTOR
Q7604 or 2SB1462J/QR/-X TRANSISTOR
Q7605 DTC144EE-X DIGI TRANSISTOR KOPIN
Q7605 or UN9213J-X DIGI TRANSISTOR KOPIN
Q7605 or RN1104-X DIGI TRANSISTOR KOPIN
Q7605 or BCR148T-X DIGI TRANSISTOR KOPIN
Q7608 DTC144EE-X DIGI TRANSISTOR
Q7608 or UN9213J-X DIGI TRANSISTOR
Q7608 or RN1104-X DIGI TRANSISTOR
Q7608 or BCR148T-X DIGI TRANSISTOR
Q7609 DTC144EE-X DIGI TRANSISTOR
Q7609 or UN9213J-X DIGI TRANSISTOR
Q7609 or RN1104-X DIGI TRANSISTOR
Q7609 or BCR148T-X DIGI TRANSISTOR
Q7610 DTA144EE-X DIGI TRANSISTOR
Q7610 or UN9113J-X DIGI TRANSISTOR
Q7610 or RN2104-X DIGI TRANSISTOR
Q7610 or BCR198T-X DIGI TRANSISTOR
D7602 BAS16-03W-X SI DIODE
D7604 MA8068-X Z DIODE
C1 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C10 NCB31CK-104X C CAPACITOR 0.1uF 16V K K,L,M,N
C11 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M K,L,M,N
C7601 NCB21CK-105X C CAPACITOR 1uF 16V K
C7603 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C7604 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C7605 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C7606 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7607 NCB41CK-106X C CAPACITOR 10uF 16V K
C7609 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7610 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C7611 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C7612 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C7613 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C7614 NCB31HK-152X C CAPACITOR 1500pF 50V K
C7616 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7618 NBE90JM-106X TA E CAPACITOR 10uF 6.3V M
C7619 NBE90JM-106X TA E CAPACITOR 10uF 6.3V M
C7621 NCB21CK-105X C CAPACITOR 1uF 16V K
C7622 NCB21CK-105X C CAPACITOR 1uF 16V K
C7623 NBE21AM-106X TA E CAPACITOR 10uF 10V M
C7624 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7625 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C7626 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7627 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C7628 NBP41EM-475X-B TA E CAPACITOR 4.7uF 25V M
C7629 NBP21CM-335X TA E CAPACITOR 3.3uF 16V M
C7630 NBP41EM-475X-B TA E CAPACITOR 4.7uF 25V M
C7632 NBP41EM-475X-B TA E CAPACITOR 4.7uF 25V M
C7634 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C7637 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7639 NBP41CM-106X TA E CAPACITOR 10uF 16V M
C7642 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C7653 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7654 NCB21AK-105X C CAPACITOR 1uF 10V K
C7655 NBE21AM-106X TA E CAPACITOR 10uF 10V M
R3 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R5 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R6 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R7 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J K,L,M,N
R8 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J K,L,M,N
R9 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J K,L,M,N
R18 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J K,L,M,N
R19 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J K,L,M,N
R21 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J K,L,M,N
R22 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J K,L,M,N
R23 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J K,L,M,N
R25 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J K,L,M,N
R29 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J K,L,M,N
R30 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J K,L,M,N
R31 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J K,L,M,N
R32 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J K,L,M,N
R7601 NRVA63D-622X CMF RESISTOR 6.2k Ω 1/16W D
R7602 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R7604 NRSA63D-273X MG RESISTOR 27k Ω 1/16W D
R7605 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7606 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7607 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7608 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R7609 NRVA63D-223X CMF RESISTOR 22k
Ω 1/16W D
R7610 NRVA63D-433X CMF RESISTOR 43k
Ω 1/16W D
R7611 NRVA63D-821X CMF RESISTOR 820 Ω 1/16W D
R7612 NRVA63D-223X CMF RESISTOR 22k Ω 1/16W D
R7613 NRVA63D-223X CMF RESISTOR 22k Ω 1/16W D
R7614 NRVA63D-223X CMF RESISTOR 22k Ω 1/16W D
R7615 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7616 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7617 NRSA02J-330X MG RESISTOR 33 Ω 1/10W J
R7618 NRSA02J-330X MG RESISTOR 33 Ω 1/10W J
R7619 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R7621 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7622 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7630 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7634 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7636 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7637 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7638 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7639 NRSA63D-912X MG RESISTOR 9.1k Ω 1/16W D
R7640 NRSA63D-273X MG RESISTOR 27k Ω 1/16W D
R7641 NRSA63D-332X MG RESISTOR 3.3k Ω 1/16W D
R7642 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R7645 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7647 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7648 NRSA63D-183X MG RESISTOR 18k Ω 1/16W D
R7651 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7653 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7654 NRSA63D-122X MG RESISTOR 1.2k Ω 1/16W D
R7655 NRSA63D-333X MG RESISTOR 33k Ω 1/16W D
R7663 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R7664 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7665 NRSA63D-683X MG RESISTOR 68k
Ω 1/16W D
R7666 NRSA63D-473X MG RESISTOR 47k
Ω 1/16W D
R7667 NRSA63D-561X MG RESISTOR 560 Ω 1/16W D
L10 NQR0129-002X FERRITE BEADS K,L,M,N
L7601 NQL38DK-100X P COIL 10uH K
L7602 NQL38DK-100X P COIL 10uH K
L7603 NQL38DK-100X P COIL 10uH K
L7604 NQL38DK-100X P COIL 10uH K
L7605 NQL38DK-100X P COIL 10uH K
L7607 NQL38DK-100X P COIL 10uH K
CN761 QGF0508F1-40X CONNECTOR
MAIN FFC/FPC (1-40)
CN762 QGF0532F2-10X CONNECTOR DSC FFC/FPC (1-10) K,L,M,N
CN763 QGF0532F2-20X CONNECTOR
2.5 FFC/FPC (1-20)
CN765 QGF0506F2-32X CONNECTOR LCD BL FFC/FPC (1-32)
CN766 NNZ0058-001X SD CARD CONNE SD/MMC K,L,M,N
J7601 QND0087-001 S JACK
SW2 NSW0198-001X TACT SWITCH STOP
SW3 NSW0198-001X TACT SWITCH REW
SW4 NSW0198-001X TACT SWITCH FF
SW5 NSW0198-001X TACT SWITCH PLAY/PAUSE
SW6 NSW0099-001X SLIDE SWITCH DSC K,L,M,N
SW7 NSW0198-001X TACT SWITCH K,L,M,N
SW8 NSW0198-001X TACT SWITCH K,L,M,N
SW7601 QSW0451-001 DETECT SW 2.5 OPN SW
OT1 LY30030-0V7A SPACER(A) (x2)
 Symbol No. Part No. Part Name Description Local
MODEL MARK
GR-D23EK
GR-D23EX
GR-D23EY
GR-D23EZ
A
B
C
D
MODEL MARK
GR-D33EK
GR-D53EK
GR-D53EX
GR-D53EY
E
F
G
H
MODEL MARK
GR-D53EZ
GR-D73EK
GR-D73EX
GR-D73EY
J
K
L
M
MODEL MARK
GR-D73EZ N
