JVC GR-D33EK - Page 131

3-20(No.YF008)
BL2.5 BOARD ASSEMBLY <03>
CCD BOARD ASSEMBLY <04>
PREMDA BOARD ASSEMBLY <05>
WR1 QUQ105-4007AA FFC WIRE MAIN-M.FFC
WR2 QUQ105-1007AA FFC WIRE MAIN-M.FFC K,L,M,N
 Symbol No. Part No. Part Name Description Local
PW1 YB20964A BL2.5 BOARD ASSY
IC7504 DN8797MS-X IC TEZUKE
Q7501 2SD1664/QR/-W TRANSISTOR
Q7502 2SD1664/QR/-W TRANSISTOR
Q7503 DTA144EE-X DIGI TRANSISTOR
Q7503 or UN9113J-X DIGI TRANSISTOR
Q7503 or RN2104-X DIGI TRANSISTOR
Q7503 or BCR198T-X DIGI TRANSISTOR
Q7504 DTC144EE-X DIGI TRANSISTOR
Q7504 or UN9213J-X DIGI TRANSISTOR
Q7504 or RN1104-X DIGI TRANSISTOR
Q7504 or BCR148T-X DIGI TRANSISTOR
C7501 NCZ1016-120X C CAPACITOR 12pF 2kV J
C7502 NCB21EK-273X C CAPACITOR 0.027uF 25V K
C7503 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7504 NCB10JK-106X C CAPACITOR 10uF 6.3V K
R7501 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R7502 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7503 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7504 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7511 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7512 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7513 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7501 NQLZ010-680X COIL 68uH
T7501 NQS0056-001X SW TARNSF
CN7601 QGF0534F1-16X CONNECTOR FFC/FPC (1-16)
CN7602 QGF0534F1-16X CONNECTOR FFC/FPC (1-16)
CN7603 QGF0534F1-24X CONNECTOR FFC/FPC (1-24)
 F7501 NMFZ007-R40X-K FUSE 0.4A 50V
WR1 QAL0464-001 FPC TEZUKE
 Symbol No. Part No. Part Name Description Local
PW1 YB20963A-01-SS CCD BOARD ASSY K,L,M,N
PW1 YB20963B-01-SS CCD BOARD ASSY A,B,C,D,E,F,G,H,J
Q5001 2SC3931/CD/-X TRANSISTOR
Q5002 2SC4081/QR/-X TRANSISTOR 2SC4081 K,L,M,N
Q5002 or BC847BW-X TRANSISTOR K,L,M,N
C5001 NBP41EM-475X-B TA E CAPACITOR 4.7uF 25V M
C5002 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5003 NBE21AM-106X TA E CAPACITOR 10uF 10V M
C5004 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5005 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5006 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5007 NCB31EK-222X C CAPACITOR 2200pF 25V K
R5001 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R5002 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R5005 NRS181J-472X MG RESISTOR 4.7k Ω 1/8W J K,L,M,N
R5007 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
L5001 NQL144K-100X P COIL 10uH K
L5002 NQL38DK-100X P COIL 10uH K
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
PW1 YB10445A-02 PREMDA BOARD ASSY
 IC1601 BD6637KV IC MDA 64PIN
IC1701 BA10358FVM-W IC REELAMP5V
IC1702 LM393DR-X IC REELSMT
IC3501 JCY0132 IC
IC3502 SN74AHC1G04K-X IC
IC3502 or SN74AHC1G04DC-X IC(DIGITAL)
Q1601 UMC3N-W DIGI TRANSISTOR LD ON
D1602 DAP222-X DIODE ARRAY LD OUT
D1602 or MA132WA-X SI DIODE
D1603 DAP222-X DIODE ARRAY LD ON
D1603 or MA132WA-X SI DIODE
D1604 DAP222-X DIODE ARRAY C.ERR-3V
D1604 or MA132WA-X SI DIODE
C1601 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C1602 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C1603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C1605 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1606 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1607 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C1614 NBE21AM-106X TA E CAPACITOR 10uF 10V M
C1618 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1619 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1620 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1621 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C1622 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1623 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C1624 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C1625 NCS31HJ-101X C CAPACITOR 100pF 50V J
C1626 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1627 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1628 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C1629 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1630 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1631 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C1632 NCB21CK-474X C CAPACITOR 0.47uF 16V K
C1633 NCB21CK-474X C CAPACITOR 0.47uF 16V K
C1701 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1702 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3501 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C3502 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C3503 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C3504 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C3505 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C3506 NCB21AK-105X C CAPACITOR 1uF 10V K
C3507 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3508 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3509 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3510 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3511 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3512 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3513 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3514 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C3515 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C3516 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C3517 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3518 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3519 NCB31HK-102X C CAPACITOR 1000pF 50V K
C3520 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3521 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3522 NCB20JM-475X C CAPACITOR 4.7uF 6.3V M
C3523 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3524 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3525 NCB20JM-475X C CAPACITOR 4.7uF 6.3V M
C3526 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3527 NDC31HJ-221X C CAPACITOR 220pF 50V J
C3528 NCB31EK-103X C CAPACITOR 0.01uF 25V K
R1601 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R1602 NRSA63J-124X MG RESISTOR 120k
Ω 1/16W J
R1603 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1604 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
MODEL MARK
GR-D23EK
GR-D23EX
GR-D23EY
GR-D23EZ
A
B
C
D
MODEL MARK
GR-D33EK
GR-D53EK
GR-D53EX
GR-D53EY
E
F
G
H
MODEL MARK
GR-D53EZ
GR-D73EK
GR-D73EX
GR-D73EY
J
K
L
M
MODEL MARK
GR-D73EZ N
