JVC GR-DVF10 Technical Guide

2-33
•
••
•
Deck DSP (IC3001: JCY0106-2) pin functions (5/6)
Pin No. Label In/Out Description
46 TESTIO [22]
112 TESTIO [23]
171 VDD - Power supply
248 - - Not used
47 SCANENABLE
113 SCANMODE
214 TRST In Reset signal input for boundary scan
172 TDI - H: Fixed (Not used)
48 TCK - L: Fixed (Not used)
249 TMS - H: Fixed (Not used)
114 TDO - Open (Not used)
215 TEST - L: Fixed (Not used)
173 VDD - Power supply
49 PHYDATA [3]
115 PHYDATA [2]
50 PHYDATA [1]
174 PHYDATA [0]
116 VDDS - Power supply
51 SCLK Out IEEE1394 system clock (49.152MHz), (To 1394PHY:IC3101)
175 LOCONT - H: Fixed
117 XPHYISO Out Link interface isolation status (H: Enable), (To 1394PHY: IC3101)
52 PHYCTL [1]
176 PHYCTL [0]
118 PHYLREQ - IEEE1394 link request signal output, (To 1394PHY:IC3101)
53 GND - Ground
119 VDD - Power supply
54 EXTCLKIN
177 EXREQ
216 EXRW - H: Fixed (Not used)
250 EXREADEMPTY
120 EXWRITEFULL
55 VDDS - Power supply
178 - - Not used
121 EXTDATA [0]
217 EXTDATA [1]
56 EXTDATA [2]
251 EXTDATA [3]
179 EXTDATA [4]
122 EXTDATA [5]
57 EXTDATA [6]
218 EXTDATA [7]
180 VDD - Power supply
123 GND - Ground
In/Out Link interface data input/output, (From/To 1394PHY: IC3101)
Open (Not used)-
L: Fixed (Not used)-
L: Fixed (Not used)-
Link interface control (H: output), (From/To 1394PHY: IC3101)In/Out
Open (Not used)-
Open (Not used)-
Table 2-5-4 Deck DSP (IC3001: JCY0106-2) pin functions (5/6)
