JVC GR-DVL320A Service Manual

2
MONITOR ASSEMBLY <M5>
500 MONITOR ASSY LYH20246-036A LYH20246-036B *LYH20246-036C LYH20246-036B LYH20246-040B LYH20246-040C
501 MONITOR COVER(2.5)ASSY LY20808-001A *LY20808-001B LY20808-001A LY20808-002A LY20808-002B
501F WINDOW(MONI2.5) ———————*LY32378-009A
506 BACK LIGHT QLL0093-001 *QLL0121-001 *
QLL0093-001 *QLL0121-001 * * *
!
REF.
MODEL
GR-DVL160EG-X GR-DVL320A GR-DVL320A-S GR-DVL320EA GR-DVL322SH GR-DVL520A GR-DVL520EA GR-DVL522SH
NO.
ITEM
MAIN BOARD ASSEMBLY <01>
PW MAIN BOARD ASSY YB10359PC-03 YB10359PA-03 YB10359PG-02
IC1001 IC(MICRO C ROM) UPD703039F1-A25 UPD703039F1-A26
IC1301 IC SN74LV08APW ———
IC1302 IC MAX3221CAE ———
IC1401 IC(MICRO C ROM) UPD703040YF-M09 UPD703040YF-M06
IC1402 IC(DIGITAL) TC7W66FU ———
IC4301 IC JCY0150 JCY0158
Q4802 TRANSISTOR —————2SC4617/RS/-X
Q4803 DIGI TRANSISTOR —————DTC143EE
Q4804 DIGI TRANSISTOR —————DTA144EE
Q4805 DIGI TRANSISTOR —————DTA143EE
R1028 MG RESISTOR — *NRSA6AJ-185W * * * * * *
R1059 MG REGISTOR NRSA6AJ-0R0W ———
R1307 MG REGISTOR —————NRSA6AJ-0R0W
R1308 MG REGISTOR —————NRSA6AJ-0R0W
R1415 MG REGISTOR —————NRSA6AJ-472W
R1416 MG REGISTOR —————NRSA6AJ-472W
R1427 MG REGISTOR NRSA6AJ-104W ———
R4302 MG REGISTOR —————NRSA6AJ-101W
R4825 MG REGISTOR —————NRSA6AJ-222W
R4826 MG REGISTOR —————NRSA6AJ-473W
R4837 MG REGISTOR —————NRSA6AJ-0R0W
R4846 MG REGISTOR —————NRSA6AJ-0R0W
RA4307 NETWORK RESISTOR —————NRZ0034-221W
RA4308 NETWORK RESISTOR —————NRZ0034-221W
RA4309 NETWORK RESISTOR —————NRZ0034-221W
RA4310 NETWORK RESISTOR —————NRZ0034-221W
C1301 CAPACITOR NCFA1AZ-104W ———
C1302 CAPACITOR NCFA1AZ-104W ———
C1303 CAPACITOR NCFA1AZ-104W ———
C1304 CAPACITOR NCFA1AZ-104W ———
C1305 CAPACITOR NCFA1AZ-104W ———
C1306 CAPACITOR NCFA1AZ-104W ———
CN111 CONNECTOR —————QGB0501L1-80X
!
REF.
MODEL
GR-DVL160EG-X GR-DVL320A GR-DVL320A-S GR-DVL320EA GR-DVL322SH GR-DVL520A GR-DVL520EA GR-DVL522SH
NO.
ITEM
MONITOR BOARD ASSEMBLY <02>
PW MONITOR BOARD ASSY YB10360PB-02 YB10360PY-01
D11 DIODE —————RSA6.1J4-W
R7 MG RESISTOR —————NRSA63J-103X
R8 MG RESISTOR —————NRSA63J-152X
R18 MG RESISTOR —————NRSA63J-473X
R19 MG RESISTOR —————NRSA63J-103X
R21 MG RESISTOR —————NRSA63J-103X
R22 MG RESISTOR —————NRSA63J-473X
R23 MG RESISTOR —————NRSA63J-104X
C11 T CAPACITOR —————NBE20JM-106X
L10 FERRITE BEAD —————NQR0129-002X
SW6 SLIDE SWITCH —————NSW0099-001X
SW7 TACT SWITCH —————NSW0160-001X
SW8 TACT SWITCH —————NSW0160-001X
CN762 FPC CONNECTOR —————QGF0508F1-10X
CN766 SD CARD CONNECTOR —————NNZ0058-001X
OT2 SPACER — LY43869-001A ————LY43869-001A
!
REF.
MODEL
GR-DVL160EG-X GR-DVL320A GR-DVL320A-S GR-DVL320EA GR-DVL322SH GR-DVL520A GR-DVL520EA GR-DVL522SH
NO.
ITEM
CCD BOARD ASSEMBLY <04>
PW CCD BOARD ASSY YB20914A-01 YB20914B-01
Q5202 TRANSISTOR —————2SC4081/RS/-X
R5205 MG RESISTOR —————NRSA63J-472X
!
REF.
MODEL
GR-DVL160EG-X GR-DVL320A GR-DVL320A-S GR-DVL320EA GR-DVL322SH GR-DVL520A GR-DVL520EA GR-DVL522SH
NO.
ITEM
DSC BOARD ASSEMBLY <10>
PW DSC BOARD ASSY —————YB20915E-02
!
REF.
MODEL
GR-DVL160EG-X GR-DVL320A GR-DVL320A-S GR-DVL320EA GR-DVL322SH GR-DVL520A GR-DVL520EA GR-DVL522SH
NO.
ITEM
Notes : Mark is same as left.
Mark — is not used.
Mark : * reference model was also changed.
