Controls
1 OPEN/EJECT Switch ............................ 墌 pg. 12
2 • Stop Button [5] .................................... 墌 pg. 21
• BACKLIGHT Button.............................
墌 pg. 42
3 • Rewind Button [ 2 ] ............................. 墌 pg. 21
• NIGHT Button ......................................
墌 pg. 36
4 Play/Pause Button [ 4 /6] ....................... 墌 pg. 21
5 Fast-Forward Button [ 3 ] ..................... 墌 pg. 21
6 Monitor Open Button [PUSH OPEN] ..... 墌 pg. 16
7 Diopter Adjustment Control.................... 墌 pg. 10
8 Battery Release Button
[BATT. RELEASE] ...................................
墌 pg. 8
9 Recording Start/Stop Button .................. 墌 pg. 16
0 • MENU Wheel [+, –, PUSH].................. 墌 pg. 44
• LCD Monitor BRIGHT (Brightness)
Control [+, –] ........................................
墌 pg. 16
! Snapshot Button
[SNAPSHOT] .......................
墌 pg. 26, 27, 40, 52
@ • Power Zoom Lever [T/W]..................... 墌 pg. 18
• Speaker Volume Control [VOL.] ..........
墌 pg. 21
# • FOCUS Button..................................... 墌 pg. 41
• BLANK Button .....................................
墌 pg. 24
$ Lock Button ............................................ 墌 pg. 17
% Power Switch
[
A
U
TO
,
MANUAL
, PLAY, OFF] ................. 墌 pg. 17
^ INDEX Button
(GR-DVL720/DVL520 only) ...................
墌 pg. 29
& INFO Button
(GR-DVL720/DVL520 only) ...................
墌 pg. 29
* VIDEO/MEMORY Switch [VIDEO, MEMORY]
(GR-DVL720/DVL520 only) ...................
墌 pg. 17
( Video Light Switch
[LIGHT OFF/AUTO/ON] .........................
墌 pg. 19
Connectors
The connectors ) to w are located beneath a cover.
) Audio/Video Output Connector
[AV] ............................................
墌 pg. 22, 50, 59
q • J Terminal [JLIP (Joint Level Interface Protocol)]
(GR-DVL320 only) ...............................
墌 pg. 59
You can also connect to a JLIP-compatible
camcorder or VCR to control it from the
computer using the optional Software HS-V16U.
• Edit Connector [EDIT]
(GR-DVL720/DVL520 only) .................
墌 pg. 59
w DC Input Connector ............................. 墌 pg. 8, 9
e Digital Video Connector
[DV IN/OUT] (i.Link*) .......................
墌 pg. 51, 65
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The
logo
is used for products compliant with the i.Link
standard.
r S-Video Output Connector
[S-VIDEO] ..................................
墌 pg. 22, 50, 59
t • PC Connector (GR-DVL320 only) ....... 墌 pg. 65
• USB (Universal Serial Bus) Connector
(GR-DVL720/DVL520 only) .................
墌 pg. 65
Indicators
y Tally Lamp ....................................... 墌 pg. 16, 46
u CHARGE Lamp ....................................... 墌 pg. 8
i Power Lamp .................................... 墌 pg. 16, 17
Other Parts
o • Remote Sensor.................................... 墌 pg. 53
• Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
p Viewfinder .............................................. 墌 pg. 10
Q Video Light ............................................. 墌 pg. 19
W Stereo Microphone ................................ 墌 pg. 63
E Viewfinder Cleaning Hatch .................... 墌 pg. 74
R Shoulder Strap Eyelets .......................... 墌 pg. 10
T Grip Strap .............................................. 墌 pg. 10
Y LCD Monitor .................................... 墌 pg. 16, 17
U Speaker ................................................. 墌 pg. 21
I Battery Pack Mount ................................. 墌 pg. 8
O Stud Hole ............................................... 墌 pg. 10
P Tripod Mounting Socket ......................... 墌 pg. 10
a MEMORY CARD Cover
(GR-DVL720/DVL520 only) ...................
墌 pg. 14
