# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
5-15
R8054 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8055 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8058 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8061 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8062 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8063 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W
R8065 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8066 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W
R8068 NRSA6AJ-561W MG RESISTOR 560Ø,1/16W
R8069 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8070 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W
R8073 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
RA8001 NRZ0034-101W NETWORK RESISTOR 100Ø
RA8002 NRZ0034-101W NETWORK RESISTOR 100Ø
RA8003 NRZ0034-101W NETWORK RESISTOR 100Ø
RA8004 NRZ0034-101W NETWORK RESISTOR 100Ø
C8001 NBE20JM-106X T CAPACITOR 10µF,6.3V
C8002 NBE20JM-106X T CAPACITOR 10µF,6.3V
C8003 NBE20JM-106X T CAPACITOR 10µF,6.3V
C8004 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8005 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8006 NBE20JM-106X T CAPACITOR 10µF,6.3V
C8007 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8008 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8010 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8011 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8014 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8015 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8016 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8017 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8018 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8019 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8020 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8021 NBE20JM-106X T CAPACITOR 10µF,6.3V
C8022 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8023 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8024 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8025 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8026 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8027 NCB30JK-105X CAPACITOR 1µF,6.3V
C8028 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8029 NBE20JM-106X T CAPACITOR 10µF,6.3V
C8030 NCBA1CK-103W CAPACITOR 0.01µF,16V
L8001 NQR0129-002X FERRITE BEAD
L8002 NQR0129-002X FERRITE BEAD
L8003 NQR0129-002X FERRITE BEAD
L8004 NQR0129-002X FERRITE BEAD
L8005 NQR0129-002X FERRITE BEAD
L8006 NQR0129-002X FERRATE BEADS
X8002 NAX0398-001X C OSCILLATOR
CN8001 QGB0501M1-80X CONNECTOR
CN8002 QGF0508F1-10X FPC CONNECTOR
OT1 LY30029-0X3A SPACER(A)
CN104 QGA1002C1-06X CONNECTOR
CN105 QGB0801K2-30X CONNECTOR
CN106 QGA1201C2-07X CONNECTOR
CN107 QGF0503C1-20X FFC/FPC CONNECTOR
CN108 QGF0512C1-24X FPC CONNECTOR
CN109 QGF0507F4-15X FFC/FPC CONNECTOR
CN110 QGF0505F1-08X FPC CONNECTOR
CN111 QGB0501L1-80X CONNECTOR
CN112 QGF0505F2-18X FPC CONNECTOR
CN113 QGF0508F1-33X FPC CONNECTOR
! F6101 NMFZ007-2R0X-K FUSE T2.0A
OT1 LY43491-001A SHEET(MAIN)
OT2 LY43549-001A SHEET(MECHA)
OT3 LY43770-001A SPACER(CAPSTAN)
OT4 LY43770-002A SPACER(CAPSTAN)
SD1 LY32080-001A SHIELD CASE
******************************
DSC BOARD ASSEMBLY <10>
PW YB20915C-03 DSC BOARD ASSY
IC8001 TMS320DSC24GHK IC
or TMX320DSC24GHK IC
IC8002 K4S641632E-TC1H IC
IC8003 MBV160TE90PTA39 IC(MICRO C ROM)
IC8004 S-80842ANNP-W IC
IC8006 BU2288FV IC
IC8007 MM1385EN IC
Q8001 DTA114EE DIGI TRANSISTOR
D8001 RB751V-40-X SB DIODE
R8001 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R8002 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R8003 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R8005 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8006 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W
R8007 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W
R8009 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W
R8016 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R8017 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R8020 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8022 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W
R8025 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8026 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8027 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W
R8028 NRS181J-270X MG RESISTOR 27Ø,1/8W
R8029 NRS181J-270X MG RESISTOR 27Ø,1/8W
R8030 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W
R8031 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W
R8032 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8034 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8036 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W
R8037 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R8038 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W
R8043 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W
R8046 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8048 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8050 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8051 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8053 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
