101 UPPER CASE ASSY LY20774-005B LY20774-005C LY20797-004C
101A TOP COVER LY20775-001A LY20776-001A
101J EARTHSHEET/BRACKET(EARTH) LY43540-001A *LY32886-001A * * LY32887-001A
101M SPECIAL SCREW,X2 LY30018-084A LY30018-038A
120 STICKER(SIDE) LY43566-005A LY43566-003A LY43566-005A LY43566-003A
123 SPACER(A) — LY30029-0Y5A
144 PLATE(ADJUST) LY43256-001A LY43256-001B
252 SPACER(A) — LY30029-0Z7A
PW MAIN BOARD ASSY YB10391QC YB10391PA-01 YB10391QC-02 YB10391PA-01 YB10391QA-02
IC1401 IC UPD703040YF-M09 UPD703040YF-M06 UPD703040YF-M09 UPD703040YF-M06
IC3004 IC MC74VHC1G04DF-X ——— MC74VHC1G04DF-X — MC74VHC1G04DF-X
IC3005 IC — JCY0136 — JCY0136 —
IC3007 IC JCY0174 — — — JCY0174 — JCY0174
Q3001 TRANSISTOR — 2SC4617/RS/-X — 2SC4617/RS/-X —
Q3002 TRANSISTOR — 2SC4617/RS/-X — 2SC4617/RS/-X —
R3003 MG RESISTOR NRSA6AJ-105W — — — NRSA6AJ-105W — NRSA6AJ-105W
TABLE OF CONTENTS
DIFFERENT TABLE.................................................................................................................................................................................... 1 to 2
4. CHARTS AND DIAGRAMS (4-1 to 4-8)
4.1 MAIN CIRCUIT BOARD [GR-DVL865EG-X,DVL867EG-Y] .................................................................................................................. 4-1
4.2 DSC CIRCUIT BOARD [GR-DVL865EG-X] .......................................................................................................................................... 4-7
5. PARTS LIST (5-1 to 5-7)
5.1 PACKING AND ACCESSORY ASSEMBLY <M1> ................................................................................................................................ 5-1
5.2 FINAL ASSEMBLY <M2> ...................................................................................................................................................................... 5-3
5.3 MONITOR ASSEMBLY <M5> [GR-DVL767EG-X/-Y/EK] ..................................................................................................................... 5-6
5.3 MONITOR ASSEMBLY <M5> [GR-DVL865EG-X,DVL867EG-X/-Y] ..................................................................................................... 5-7
The following table indicate main different points between models GR-DVL765EG-X, GR-DVL767EG-X,GR-DVL767EG-Y,
DVL767EK,DVL865EG-X,DVL867EG-X and GR-DVL867EG-Y.
The following table indicate different parts number between models GR-DVL765EG-X, GR-DVL767EG-X,GR-DVL767EG-Y,
DVL767EK,DVL865EG-X,DVL867EG-X and GR-DVL867EG-Y.
PACKING AND ACCESSORY ASSEMBLY <M1> Note: As for IB (INSTRUCTIONS), refer to sec.5.
!
REF.
MODEL
GR-DVL765EG-X GR-DVL767EG-X GR-DVL767EG-Y GR-DVL767EK GR-DVL865EG-X GR-DVL867EG-X GR-DVL867EG-Y
No.
ITEM
MODEL
GR-DVL765EG-X GR-DVL767EG-X GR-DVL767EG-Y GR-DVL767EK GR-DVL865EG-X GR-DVL867EG-X GR-DVL867EG-Y
ITEM
LCD MONITOR 2.5” 3.5”
DV TERMINAL OUTPUT ONLY IN/OUT OUTPUT ONLY IN/OUT
Notes : Mark is same as left. Mark — is not used. Mark * reference model was also changed.
1
!
REF.
MODEL
GR-DVL765EG-X GR-DVL767EG-X GR-DVL767EG-Y GR-DVL767EK GR-DVL865EG-X GR-DVL867EG-X GR-DVL867EG-Y
No.
ITEM
FINAL ASSEMBLY <M2>
MONITOR ASSEMBLY <M5>
!
REF.
MODEL
GR-DVL765EG-X GR-DVL767EG-X GR-DVL767EG-Y GR-DVL767EK GR-DVL865EG-X GR-DVL867EG-X GR-DVL867EG-Y
No.
ITEM
500 MONITOR ASSY LYH20246-043B LYH20246-042B
501 MONITOR COVER ASSY LY20863-001B LY20864-001C
501F EARTH MON LY43784-001A LY43785-001A
501G WINDOW(M.MEGA) LY32704-001A LY32704-002A
501H PLATE LY32706-001B LY32707-001B
502 MONITOR CASE ASSY LY20874-001A LY20598-002A
504 HOLDER LY20674-001A LY20568-001A
506 BACK LIGHT QLL0121-001 QLL0123-001
507 LCD MODULE QLD0154-001 QLD0203-001
511 SPEACER(A) — * LY30029-0Y4A * * ———
512 SPEACER(A) — — — — LY30029-0Y6A
!
REF.
MODEL
GR-DVL765EG-X GR-DVL767EG-X GR-DVL767EG-Y GR-DVL767EK GR-DVL865EG-X GR-DVL867EG-X GR-DVL867EG-Y
No.
ITEM
MAIN BOARD ASSEMBLY <01>
1 PACKING CASE LY32567-021A LY32567-008A
2 CUSHION LY32568-001A *LY32923-001C LY32568-001A
4 POLY BAG QPA02003506 YQM30061-3 QPA02003506
7 SHEET(AGREMENT) LYT0934-001A ———
8 SHEET(E.UE) LYT0889-010A — LYT0889-010A
9 SHEET(ATT.) — * LYT0909-015A * * * * *
10 GUARANTY CARD — — — BT-54008-2 — — —
11 PAMPHLET(EK) — — — LYT0867-001A — — —
! 26 POWER CORD QMPL120-190-JR QMPP110-190-JR QMPL120-190-JR
34 CD ROM ASSY LY32210-023A LY32210-038A
38 WARRANTY CARD BT-54013-2 — BT-54013-2
40 CORE FILTER QQR0919-002 — — — — — —
42 STICKER(EK) — — — LY43496-001A — — —
43 Q.CARD(JUK) — — — LYT0194-001B — — —
44 POLY BAG — — — — * QPA02502505P * *
