10
1 • MENU Wheel [–, +] ..................................... pg. 18
• BRIGHT Wheel [–, +] .................................. pg. 11
• TRACKING Wheel [–, +] ............................. pg. 14
2 Snapshot Button [SNAPSHOT] ..................... pg. 12
3 • Power Zoom Lever [T/W] ............................ pg. 13
• Speaker Volume Control [VOL.] .................. pg. 11
4 • Picture Stabilizer Button
[P.STABILIZER] ........................................... pg. 12
• Time Base Corrector Button [TBC] .............. pg. 14
5 S-Video Output Connectors [S] ..................... pg. 15
6 Audio Output Connector [A] .......................... pg. 15
7 Video Output Connector [V] .......................... pg. 15
8 Battery Release Switch
[BATTERY RELEASE] .................................... pg. 6
9 DC IN Connector ............................................. pg. 6
0 Digital Connector [DIGITAL]
! Recording Start/Stop Button ......................... pg. 11
@ Power Switch [
, OFF, , ] .............. pg. 11
# Video Light Switch
[LIGHT OFF/AUTO/ON] ................................ pg. 13
$ Stop Button [STOP] ....................................... pg. 11
% • Retake Rewind Button [RETAKE R] ............ pg. 13
• Quick Review Button [
R] ...................... pg. 13
• Rewind Button [R] ....................................... pg. 11
^ Play/Pause Button ......................................... pg. 11
& • Retake Forward Button [RETAKE F] ........... pg. 13
• Fast-Forward Button [F] .............................. pg. 11
* CHARGE Lamp ............................................... pg. 6
( POWER/REFRESH Lamp .............................. pg. 6
) • Fade/Wipe Button [FADE/WIPE] ................. pg. 22
• Counter Reset/Memory Button
[COUNTER R/M] ......................................... pg. 14
q Program AE Button [P.AE] ............................. pg. 23
w Digital Effect Button [DIGIFECT] ................... pg. 23
e NIGHT-ALIVE Button .................................... pg. 22
r REFRESH Button ............................................ pg. 6
t EJECT Switch ................................................. pg. 8
y Shoulder Strap Eyelets ................................... pg. 8
u Battery Pack Mount ......................................... pg. 6
i Close Button .................................................... pg. 8
o Diopter Adjustment Control ............................. pg. 8
p • Camera Sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
• Remote Sensor* ...................................... pg. 9, 17
Q Grip Strap ........................................................ pg. 8
W Tripod Mounting Socket .................................. pg. 8
E Infrared Beam Transmitting Window ......... pg. 9, 17
R ZOOM (T/W) Buttons .............................. pg. 13, 24
T PLAY Button .................................................. pg. 11
Y REW Button (Functions the same as %)
U STOP Button (Functions the same as $)
I INSERT Button .............................................. pg. 24
O • REC TIME Button ........................................ pg. 24
• ANIM. Button ............................................... pg. 24
P START/STOP Button (Functions the same as !)
a FF Button (Functions the same as &)
s PAUSE Button ............................................... pg. 11
d A.DUB Button ................................................ pg. 24
f • INT.TIME Button .......................................... pg. 24
• SELF TIMER Button (non-functional)
1 Tape Remaining Time ................................... pg. 21
2 Recording Mode Indicator ............................. pg. 20
3 • Digital Effect Indicator ................................. pg. 23
• Program AE Indicator .................................. pg. 23
• Night-Alive Indicator .................................... pg. 22
• Fade/Wipe-Standby Indicator ...................... pg. 22
4 Recording Format Indicator (S/S-ET) ............ pg. 20
5 Tape Length Indicator .................................... pg. 21
6 Zoom Indicator Bar ........................................ pg. 13
Zoom Level Indicator
Approximate Zoom Ratio
7 Recording Indicator ....................................... pg. 11
8 Digital Effect Indicator ................................... pg. 23
9 • Program AE Indicator .................................. pg. 23
• Night-Alive Indicator .................................... pg. 22
0 Fade/Wipe-Standby Indicator ........................ pg. 22
! Picture Stabilizer Indicator ............................ pg. 12
@ Interval Time/Recording Time Indicator ........... pg. 21
# Bright Level Indicator .................................... pg. 11
$ Instant Title Display ....................................... pg. 19
% Date/Time Display ......................................... pg. 19
^ Focus Indicator .............................................. pg. 18
& Exposure Control Level Counter ................... pg. 18
* White Balance Mode Indicator ...................... pg. 19
( S-VHS/S-VHS ET Recording
Indicator ........................................................ pg. 20
) Record-Standby Mode Indicator ................... pg. 11
q • : Cassette Indicator ................................. pg. 8
• w: Insert Editing Indicator* .......................... pg. 24
w TBC Indicator ................................................ pg. 14
e Playback Special Effect Indicator .................. pg. 14
r Recording Format Indicator (S/S-ET) ............ pg. 20
t Tape Counter* ......................................... pg. 14, 24
y Recording Mode Indicator (SP/EP) ............... pg. 20
u Tape Running Indicator
4
: Playback
3
: Fast-Forward/Shuttle Search
2
: Rewind/Shuttle Search
6 : Pause
e
4
: Audio Dubbing*
i Tracking Indicator .......................................... pg. 14
o Tape Counter* ............................................... pg. 24
p • BRIGHT: Bright Level Indicator ................... pg. 11
• VOLUME: Speaker Volume Indicator ........... pg. 11
* GR-SXM745 only.
