JVC HX-C6 Service Manual

3-12
Wiring
Block No. [0][5]
R409 2007-000781 CHIP RESISTOR 33 Ω
R410 2007-000781 CHIP RESISTOR 33 Ω
R201L 2007-000282 CHIP RESISTOR 100K Ω
R202L 2007-000290 CHIP RESISTOR 100 Ω
BD201 3301-001495 FERRITE BEADS 120 Ω
CW101 3708-001252 CONNECTOR 16P 1mm
CW102 3708-002060 CONNECTOR 19P 1.25mm
CW104 3711-001136 CONNECTOR 8P
CW106 AH39-20561P CONNECTOR 6P 150mm
CW107 3708-002050 CONNECTOR 15P 1mm
CW108 3711-002348 CONNECTOR 2P
CW109 3711-002526 CONNECTOR 3P
X201 2802-000211 C RESONATOR 16.93MHz
X202 2802-001189 C RESONATOR 8MHZ
XXXXX AH41-00811A CD PCB
 Symbol No. Part No. Part Name Description Local
XXXXX 3809-001298 FLAT CABLE 12P
XXXXX 3809-001327 FLAT CABLE 17P
XXXXX 3809-001452 FLAT CABLE 24P
XXXXX 3809-001680 FLAT CABLE 19P
XXXXX 3809-001707 FLAT CABLE 30P
XXXXX AH39-00320C FM WIRE
 Symbol No. Part No. Part Name Description Local
