JVC HX-Z1R - Page 46

HX-Z1R
HX-Z1R
3-4
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 GV10115-003A
FRONT PANEL
1
2 GV40313-001A
FELT SPACER
2
3 GV40077-002A
JVC BADGE
1
4 GV30293-002A
FUNCTION LENS A
1
5 GV30294-002A
FUNCTION LENS B
1
6 GV30295-002A
FUNCTION LENS C
1
7 GV30296-001A
FL LENS
1
8 GV10114-003A
WINDOW FRAME
1
9 QYSDSF2608Z
SCREW
2
W.FRAME/F.PNL
10 GV20171-003A
WINDOW SCREEN
1
11 LV40744-001A
SOCKET BOLT
4
W.SCREEN/F.PNL
12 GV30309-003A
POWER BUTTON ASSY
1
13 GV30288-001A
CD EJECT BUTTON
1
14 GV30290-002A
CD BUTTON
1
15 GV30289-002A
FUNCTION BUTTON
1
16 GV20169-001A
CONTROL BUTTON
1
17 QYSDSF2608Z
SCREW
1
W.FRAME GROUND
18 QYSDSF2608Z
SCREW
8
PWB BRD./F.PANE
19 QYSDSF2608Z
SCREW
1
REMOTE BRD./F.P
20 QYSDSF2608Z
SCREW
9
MICOM PWB/F.PNL
21 GV30082-002A
STAY BRACKET
1
22 QYSDSF2608Z
SCREW
4
STY.BRKT.+F.PNL
23 GV30301-001A
SUPPORT BRACKET
1
24 QYSDSF2608Z
SCREW
4
SPT.BRKT.+F.PNL
25 QYSDSF2608Z
SCREW
1
SPT.BRKT + WIN.
26 GV30303-001A
PRESET RING
1
27 GV30302-001A
SOUND MODE RING
1
28 QYSDSF2608Z
SCREW
1
PRE.RING/F.PANE
29 QYSDSF2608Z
SCREW
1
S.M.RING/F.PANE
30 E65923-003
TAPPING SCREW
1
PHONE BRD./F.PN
31 GV40342-001A
FL SHEET
2
32 GV40343-001A
VINYL TUBE
1
33 GV30315-001A
CASS.HOLD.ASSY
1
34 GV30311-001A
EJECT SYS.ASSY
1
35 GV40034-001A
DAMPER ASSY
1
36 VKY4180-401
CASSETTE SPRING
2
37 GV40317-001A
HOLDER SPRING
1
38 ---------------
CASSETTE MECHA
1
39 VKL7850-002
EJECT SAFTY(A)
1
40 VKW5258-003
TORSION SPRING
1
EJECT SAFETY(A)
41 GV30124-001A
TRANS SHIELD
1
42 GV40170-003A
SPACER
1
STICK AT SLC(M)
43 QYSBSF3012Z
SCREW
2
MECHA/F.PANEL
44 QYSBSF3010Z
SCREW
2
E.ARM BKT./F.PL
45 QYSBSG3010Z
T.SCREW
2
MECHA/E.ARM BKT
46 ---------------
CD CHANGER MECHA
1
47 KSM-213CCMJ
CD MECHA ASSY
1
48 LV42763-001A
INSULATOR
2
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
49 LV42763-002A
INSULATOR
2
50 VKS3703-00R
CLAMPER ASSY
1
51 QYSPST2606Z
SCREW
1
52 VKW5187-001
ROD
1
53 QUQ610-1609AJ
FLAT WIRE
1
54 VDM1001-M002AV
WIRE & TUBE
1
55 QYSBSF2608Z
T.SCREW
4
56 VYSA1R2-033
SPACER
1
FOR VDM1001-M00
58 GV10111-001A
CHASSIS BASE
1
59 GV40313-002A
FELT SPACCER
2
CHASS BASE FOOT
60 GV30279-002A
HEAT SINK
1
61 GV30281-001A
BASE BRACKET
1
62 QYSBSG3014E
T.SCREW
4
FOR POWER IC
63 GV40297-001A
LEAF SPRING
1
64 QYSBSG3014E
T.SCREW
1
FOR LEAF SPRING
65 QYSDSTL4008Z
SPECIAL SCREW
4
FOR TRANS/CH.BS
66 QYSBSFG3016Z
SCREW
1
PRI.BRD/CH.BASE
67 QYSBSGG3008E
T.SCREW
1
FMC BRD./CH.BS
68 QYSBSG3014E
T.SCREW
2
BASE BRKT/H.SIN
69 QYSBSG3008E
T.SCREW
2
CH.BS./BS.BRKT.
70 QZW0033-001
STRAIN RELIEF
1
71 QYSBSGY3008E
SPECIAL SCREW
3
F.PANEL/CH. BAS
72 GV10112-005A
REAR PANEL
B,E,EN
1
GV10112-006A
REAR PANEL
EV
1
73 QYSBSG3010Z
T.SCREW
2
C3 MECHA/S.BRKT
74 GV30278-001A
FAN BARCKET
1
75 QYSBSGY3008E
SPECIAL SCREW
2
R.PANEL/FAN.BRK
76 GV30277-001A
REAR BRACKET
1
77 QYSBSG3010Z
T.SCREW
2
R.BRKT./CD MECH
78 QYSBSGY3008E
SPECIAL SCREW
3
R.BRKT./R.PANEL
79 QYSBSGY3008E
SPECIAL SCREW
1
REAR PNL/CHAS.B
80 QYSBSGY3008E
SPECIAL SCREW
1
REAR PNL/ AUX
81 QYSBSGY3008E
SPECIAL SCREW
2
SPK/ REAR PANEL
82 QYSBSGY3008E
SPECIAL SCREW
2
TUNER/REAR PANE
83 QYSBSGY3008E
SPECIAL SCREW
1
OPTICAL/R.PANEL
84 QYSBSGY3008E
SPECIAL SCREW
1
INNER BAR/R.PNL
85 GV10110-001A/S/
METAL COVER
1
86 QYSDSG3006M
T.SCREW
2
M.COVER/C.BASE
87 QYSBSGY3008E
SPECIAL SCREW
6
M.COVER/R.PANEL
88 GV20166-001A
CD FITTING 1
1
DISC 1
89 GV20167-001A
CD FITTING 2
1
DISC 2
90 GV20168-001A
CD FITTING 3
1
DISC 3
91 GV30299-001A
SD. MODE KNOB
2
92 GV30297-002A
VOLUME LENS
1
93 QYSDSF2608Z
SCREW
2
VOL.LEN/F.PANEL
94 GV30262-002A
VOLUME ORNAMENT
1
95 GV30298-001A
VOLUME KNOB
1
96 GV30286-001A
INNER BAR
1
