JVC HX-Z1R

3-7
HX-Z1R
Item
Parts number Parts name Area
A
Parts list (Speaker assembly)
Q'ty
Description
Block No. M2MM
A HXZ1R-SPBOX-L
SP BOX ASSY(L)
1
B HXZ1R-SPBOX-R
SP BOX ASSY(R)
1
1 ---------------
CABINET ASSY(L)
1
2 ---------------
CABINET ASSY(R)
1
3 993060500030
5CM TWEETER
2
4 991091000047
10CM WOOFER
2
FOR TOP SIDE
5 991081000048
10CM WOOFER
2
FOR BOTTOM SIDE
6 991061650046
16CM SUBWOOFER
2
7 199734300149
FRONT PANEL(L)
1
8 199734300150
FRONT PANEL(R)
1
9 151733601104
SIDE PANEL(L)
1
10 151733601105
SIDE PANEL(R)
1
11 135604161053
SCREW(M4X16)
8
FOR FRONT PANEL
12 135604201054
SCREW(M4X20)
16
FOR SIDE PANEL
13 135604201046
SCREW(M4X20)
8
FOR SUBWOOFER
14 135604121055
SCREW(M4X12)
4
FOR TWEETER
15 135604161047
SCREW(M4X16)
16
FOR WOOFER
16 109760511072
FOAM GASKET
2
