JVC HX-Z1R

3-11
HX-Z1R
Item
Parts number Parts name Area
A
Parts list (Cassette mechanism)
Q'ty
Description
Block No. MPMM
1 VKS1165-00J
CHASSIS B.ASS'Y
1
2 VKS2274-002
REEL GEAR
2
3 VKW5286-002
B.T. SPRING
2
4 VKS5559-001
PLAY IDLE GEAR
1
5 VKS5595-002
BLIND
1
6 VKS5560-003
FR IDLE GEAR
1
7 LV42013-001A
EARTH SPRING
1
8 SLC-RP3SVM
HEAD MOUNT
1
9 VKY3149-002
CASSETTE SP.
1
10 LV31786-001A
PLAY SW LEVER
1
11 VKS1166-004
CONTROL CAM
1
12 VKW5279-002
HEAD BASE SP(R)
1
13 VKW5280-001
HEAD BASE SP(L)
1
14 LV41584-001A
BRAKE(R)
1
15 LV41585-002A
BRAKE(L)
1
16 QYSBSF2005Z
T.SCREW
1
17 VKS5603-00G
MAIN PULLEY ASY
1
18 VKS3785-001MM
FR ARM
1
19 VKW5284-002
SWING SPRING
1
20 VKS2278-003
TRIGGER ARM
1
21 VKW5301-001
FR SPRING
1
22 VKW5266-001
ELEVATOR SPRING
1
23 WDL214025
WASHER
1
24 QYSBSF2005Z
T.SCREW
1
25 VKS3786-00G
CLUTCH ASS'Y
1
26 VKF3205-00B
F.WHEEL ASSY(R)
1
27 WDL183425
SLIT WASHER
1
28 VKF3207-00B
F.WHEEL ASSY(L)
1
29 WDL173525-6
SLIT WASHER
1
30 VKZ3174-00A
DC SOLENOID
1
31 LV42836-001A
CAPSTAN BELT
1
32 MSI-5U2LWA
D.C.MOTOR ASS'Y
1
33 VKR4761-001
MOTOR PULLEY
1
34 QYSPSP2604Z
SCREW
2
35 QYSBSF2608Z
T.SCREW
3
FOR P.W.B.
